• Smaller size with lower EPA
  • Water shedding design
  • New Adjustable Reflector
  • Die cast door frame held captive when opened
  • Ballast compartment separated by anodized aluminum die formed wall
  • Silicone gasket for durable weatherproofing & easy relamping
  • Stainless steel external hardware
View Technical Specs
Performance
Watts 320W
Color Temp
Lumens 31000
Efficacy 84.2 lm/W
Color Accuracy CRI
L70 Lifespan 0 hours
Type CWA HPF QT
120V 2.6/3.2A
208V N/A
240V N/A
277V N/A
Input Watts 368.00W
Dimensions
Link to Dimension Drawing

Weight: 30.7 lbs

Technical Specifications
Electrical

Photocell

120V Swivel Photocell Included. Photocell is only compatible with 120V.

Socket

3 socket positions customize beam spread to the application (center position is standard). Porcelain socket pulse rated 4kv, 1500 watts and 600 volts, reinforced with cat's eyes for added durability. Silicone and fiberglass #14 gauge socket leads rated for 200°C. Plated screw shell designed to resist corrosion with spring loaded center contact.

Pulse Start

Pulse Start metal halide for increased lamp life, lumen maintenance, color uniformity and efficiency

Listings

UL Listed

Suitable for wet locations. Suitable for ground mounting.

Construction

Housing

One-piece die-cast aluminum with die-cast door frame held captive when opened

Reflector

High quality anodized aluminum eliminates redirected energy to prolong lamp life. Contoured for maximum horizontal and vertical beam dispersion.

Finish

Formulated for high durability and long-lasting color

Lens

Thermal, tempered shock resistant glass, 5/32" thick

Lens Gasket

High-temperature extruded silicone set in die cast retaining groove. Remains in place during relamping.

EPA

2.1

Other

Patents

The unique RAB Megaflood is protected by U.S. Patents D565,772 and D570,024; China Patent ZL200730149208.0; Taiwan Patent D127,426 and Canada Patents D121,989 and D121,991

Buy American Act Compliance

RAB values USA manufacturing! Upon request, RAB may be able to manufacture this product to be compliant with the Buy American Act (BAA). Please contact customer service to request a quote for the product to be made BAA compliant.
