GUSJR4-27-850WU/TW

Spec Sheet IES File LM79 Instructions Spec Sheet EZ Layout

GUSJR4-27-850WU/TW

Affordable, easy to use LED wrap fixture

0-10V dimming, standard

50,000-Hour LED lifespan

View Technical Specs

View Price & Availability

Performance

Watts	27W
Color Temp	5000K (Cool)
Lumens	3,543 lm
Efficacy	130.7 lm/W
Color Accuracy	83 CRI
L70 Lifespan	50,000 Hours

Type	Constant Current
120V	0.22A
208V	0.16A
240V	0.11A
277V	0.10A
Input Watts	27.1W

EZ-Layout

Create Custom Lighting Layout

Dimensions

Weight: 5.3 lbs

Technical Specifications

Compliance

UL Listed

Suitable for damp locations

IESNA LM-79 & LM-80 Testing

RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.

Electrical

Driver

Constant Current, Class 2, 120-277V, 50/60 Hz, 120V: 0.22A, 208V: 0.16A, 240V: 0.11A, 277V: 0.10A

Dimming Driver

Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%.

THD

2.16% at 120V, 5.46% at 277V

Power Factor

99.6% at 120V, 93.5% at 277V

Performance

Lifespan

50,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations

Wattage Equivalency

Equivalent to (2) F32T8W

LED Characteristics

LEDs

Long-life, high-efficiency, surface-mount LEDs

Color Uniformity

RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.

Construction

Cold Weather Starting

The minimum starting temperature is -20°C (-4°F)

Maximum Ambient Temperature

Suitable for use in up to 40°C (104°F)

Housing

Sheet metal stamping 24 gauge, cold-rolled steel

Reflector

Sheet metal forming 24 gauge, cold-rolled steel with white powder coat

Lens

Prismatic Acrylic Lens

Through Wire

Fixtures can be daisy-chained with single AC input. Please refer to installation instructions for details.

Finish

Formulated for high durability and long-lasting color

Green Technology

Mercury and UV free. RoHS-compliant components.

Installation

Mounting

Surface mount. Can be mounted with v-hooks (ordered separately).

Other

5 Yr Limited Warranty

The RAB 5-year, limited warranty covers light output, driver performance and paint finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
