A19-12-E26-850-ND

Spec Sheet Photometrics Report FCC Caution Spec Sheet

A19-12-E26-850-ND

Energy-efficient replacement for incandescent and halogen lamps

Durable plastic construction reduces risk of breakage

Rated for use in enclosed and open fixtures in dry or damp locations

Frosted lens delivers smooth, diffuse light

Longer lifespan compared to legacy equivalents minimizes replacement and maintenance costs

View Technical Specs

View Price & Availability

Performance

Watts	12W
Color Temp	5000K (Daylight)
Lumens	1,100 lm
Efficacy	91.7 lm/W
Color Accuracy	80 CRI
L70 Lifespan	15,000 Hours

Input Voltage	120V
Power Factor	>0.7
Flicker	N/A
THDi	N/A

Dimensions

Weight: 0.1 lbs

Technical Specifications

Performance

Product Type

A-Line 80CRI Non Dimmable

Description

Replace conventional general purpose bulbs in open or enclosed fixtures in dry or damp environemnts.

Wattage Equivalency

75W Incandescent

Input Wattage

12W

Lumens

1,100lm

Efficacy

92lm/W

L70 Lifespan

15,000-Hour LED lifespan based on IES LM-70 results

Electrical

Power Factor

≥0.7

Dimmable

Input Voltage

120V

Operating Frequency

60 Hz

Input Current @ 120V (mA)

95mA

Operating Temperature

-13°F to 113°F (-25°C to 45°C)

LED Characteristics

Beam Angle

230°

Color Temperature

5000K

Color Accuracy (CRI)

≥80 CRI

R9 Value

High color performance with R9 no greater than 0

Color Consistency

<6-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color

Installation

Base Type

E26 Edison

Construction

Finish

White

Shape

A19

Endcap Material

Metal

Enclosure Material

Plastic

Lens Finish

Frosted

Compliance

Listings

UL Listed

Environment

Suitable for use in dry and damp environments

Fixture Rating

Suitable for use in enclosed fixtures

T20 Compliant

Not compliant

California Title 24 JA8 Compliant

Not Compliant

California Energy Commission (CEC) Status

Not Lawful for Sales in California

RoHS

Mercury and UV free. RoHS-compliant components.

FCC

Complies with Part 15B of the FCC Rules

Other

3-Year, No-Compromise Warranty

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of three (3) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
