A21-17-E26-940-DIM
A21-17-E26-940-DIM
- Produces rich and vibrant colors >90CRI
- Energy efficient replacement for incandescent and halogen lamps
- Constructed from durable plastic which lowers risk of breakage
- Rated for use in enclosed and open fixtures in dry or damp locations
- Frosted lens produces smooth diffuse light
- Longer lifespan compared to legacy equivalents minimizes replacement and maintenance costs
- ENERGY STAR Compliant, Title 20 Compliant
- Dimmable with common dimmer types (check compatibility list)
Performance
| Watts | 17W |
| Color Temp | 4000K |
| Lumens | 1,600 lm |
| Efficacy | 94 |
| Color Accuracy | 90 CRI |
| L70 Lifespan | 25,000 Hours |
| Input Voltage | 120V |
| Power Factor | N/A |
| Flicker | N/A |
| THDi | N/A |
| R9 | 50 |
Dimensions
Weight: 0.3 lbs
Technical Specifications
Performance
Product Type
A-Line 90CRI Dimmable T20
Wattage Equivalency
100W Incandescent
Input Wattage
17W
Lumens
1,600lm
Efficacy
94lm/W
L70 Lifespan
25,000-Hour LED lifespan based on IES LM-70 results
Electrical
Power Factor
>0.9
Dimmable
Yes
Dimming Type
See Dimmer Compatibility List
Input Voltage
120V
Operating Frequency
50/60Hz
Input Current @ 120V (mA)
140mA
Operating Temperature
-4°F to 113°F (-20°C to 45°C)
LED Characteristics
Beam Angle
230°
Color Temperature
4000K
Color Accuracy (CRI)
≥90
R9 Value
High color performance with R9 no less than 50
Color Consistency
<4-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color
Installation
Base Type
E26 Edison
Construction
Finish
White
Bulb Shape
A21
Endcap Material
Nickel-Aluminum
Enclosure Material
Plastic
Lens Finish
Frosted
Compliance
Listings
UL Listed
Environment
Suitable for use in dry and damp environments
Fixture Rating
Suitable for use in enclosed fixtures
Energy Star Approved
This product is ENERGY STAR® Version 2.2 Certified.
Certification Model Number
A21-17-E26-940-DIM
T20 Compliant
Can be used to conform with the requirements of California Title 20
California Title 24 JA8 Compliant
Can be used to conform with the requirements of California Title 24 Part 6
California Energy Commission (CEC) Status
Lawful for Sales in California
RoHS
Mercury and UV free. RoHS-compliant components.
FCC
Complies with Part 15B of the FCC Rules
Other
4-Year, No-Compromise Warranty
RAB warrants that our LED products will be free from defects in materials and workmanship for a period of four (4) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
