HAZFFLED60SF

Class 1, Division 2, Groups A, B, C, D

IP66 Rating protects against dust & water ingress<

DLC Listed

100,000-Hour LED lifespan

5-Year, No-Compromise Warranty

View Technical Specs

View Price & Availability

Performance

Watts	60W
Color Temp	5000K
Lumens	9,540 lm
Efficacy	155.4
Color Accuracy	70 CRI
L70 Lifespan	100,000 Hours

Type	Constant Current
120V	0.65A
208V	0.30A
240V	0.25A
277V	0.22A
Input Watts	61.4W

EZ-Layout

Create Custom Lighting Layout

Dimensions

Weight: 14.3 lbs

Technical Specifications

Hazardous Location Classifications

Class I

Class I: A hazardous location in which flammable gases or vapors may be present in the air in sufficient quantities to be explosive or ignitable, such as petroleum refineries, aircraft hangars, dry cleaning plants, utility gas plants or storage areas for liquified petroleum or natural gas, and spray finishing areas.

Division 2

Division 2: Abnormal condition, where ignitable concentrations of flammable gases, vapors or liquids are not like to exist under normal operating conditions, for example:

Closed storage drums containing flammable liquids in an inside storage room would not normal allow the hazardous vapors to escape into the atmosphere. But if one of the containers is leaking, you've got an abnormal condition.

Groups A - D

Groups A - D: The gases and vapors of Class 1 locations are broken into four groups by the Code: A,B,C, and D. These materials are grouped according to the ignition temperature of the substance, its explosion pressure, and other flammable characteristics.

Group A - The only substance in group A is acetylene because it is a gas with extremely high explosion pressures.

Group B - This group includes hydrogen and other materials with similar characteristics.

Group C & D - The most usual Class 1 groups. They comprise the greatest percentage of all Class I hazardous locations. Found in Group C is ethylene. Found in Group D are many of the most common flammable substances such as butane, gasoline, natural gas and propane.

NEC/CE T-Code

T4A

UL 844

Electric lighting fixtures for use in hazardous (classified) locations

Compliance

UL Listed

Suitable for wet locations. Suitable for mounting within 4 ft (1.2m) of the ground.

IESNA LM-79 & LM-80 Testing

RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.

IP Rating

Ingress protection rating of IP66 for dust and water

DLC Listed

This product is on the Design Lights Consortium (DLC) Qualified Products List and is eligible for rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.
DLC Product Code: S-KNUFEM

Electrical

Driver

Constant Current, Class 1, 120-277V, 50/60 Hz, 120V: 0.65A, 208V: 0.30A, 240V: 0.25A, 277V: 0.22A

Dimming Driver

Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%.

THD

2.77% at 120V, 7.86% at 277V

Power Factor

99.7% at 120V, 91.2% at 277V

Aux Power Supply

Dim to Off

Yes

Surge Protection

L/N-G 10 kV, L-N 6 kV

Optical

NEMA Type

7H x 6V Beam Spread

BUG Rating

B3 U2 G2

Construction

Cold Weather Starting

The minimum starting temperature is -40°F (-40°C)

Maximum Ambient Temperature

Suitable for use in up to 131°F (55°C)

Housing

Die-cast aluminum

Reflector

High-reflective polycarbonate

Effective Projected Area

1 Fixture: 0.41 ft²
2 Fixtures at 90°: 0.85 ft²
2 Fixtures at 180°: 0.81 ft²
3 Fixtures at 90°: 1.25 ft²
4 Fixtures at 90°: 1.25 ft²

Lens

Tempered glass

Vibration Rating

3G vibration rating per ANSI C136.31

Tilt Increment

Rotates in 6 degree increments

Gaskets

High-temperature silicone

Green Technology

Mercury and UV free. RoHS-compliant components.

Finish

Formulated for high durability and long-lasting color

Installation

Mounting

Slipfitter for 2 3/8"OD pipe

LED Characteristics

LEDs

Long-life, high-efficacy, surface-mount LEDs

Color Uniformity

RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.

Color Consistency

7-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color

Performance

Lifespan

100,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations

Wattage Equivalency

Equivalent to 250W Metal Halide (MH) or 200W High Pressure Sodium (HPS)

Other

5-Year, No-Compromise Warranty

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
