PAR20-7-927-40D-DIM

Spec Sheet Compatibility List Photometrics Report FCC Caution Spec Sheet

PAR20-7-927-40D-DIM

Produces rich and vibrant colors >90CRI

Energy efficient replacement for incandescent and halogen PAR lamps

Constructed from durable materials which lowers risk of breakage

Rated for use in enclosed and open fixtures in dry and damp locations*

Single optic and full face lens for precise beam angle control

Longer lifespan compared to legacy equivalents minimizes replacement and maintenance costs

Title 20 Compliant, ENERGY STAR Compliant, UL Listed

Dimmable down to 10% (check dimmer compatibility list)

*PAR38 is wet rated

View Technical Specs

View Price & Availability

Performance

Watts	7W
Color Temp	2700K (Soft White)
Lumens	550 lm
Efficacy	78.6 lm/W
Color Accuracy	90 CRI
L70 Lifespan	40,000 Hours

Input Voltage	120V
Power Factor	0.9
Flicker	<30%
THDi	N/A
R9	50

Dimensions

Weight: 0.2 lbs

Technical Specifications

Performance

Product Type

PAR

Input Wattage

Wattage Equivalency

50W Halogen

Lumens

550lm

Efficacy

79lm/W

L70 Lifespan

40,000 Hours

Construction

Bulb Shape

PAR20

For Use Outdoors in Open Fixtures

LED Characteristics

Color Temperature

2700K Soft White

Color Accuracy (CRI)

90 CRI

Beam Angle

40°

Installation

Base Type

E26 Edison

Electrical

Power Factor

0.9

Operating Temperature

-20°C to 45°C (-4°F to 113°F)

Dimmable

Yes, down to 10%

Input Voltage

120V

Flicker

<30%

Other

4-Year, No-Compromise Warranty

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of four (4) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.

Compliance

UL Listed

Yes

California Energy Commission (CEC) Status

Lawful for Sales in California
