STRING17-100

Spec Sheet IES File LM79 Instructions Spec Sheet EZ Layout

STRING17-100

Each LED bulb delivers 1200 lumens for a total of 12,000 lumens per fixture

Durable 100ft. SPT-2W 18/2 AWG power cord, with integrated hanging hook on each lamp

ANTI-UV protection for sun exposure and IP65 rated

Linkable strands up to 400W; a total of 4 fixtures

120V AC input voltage

View Technical Specs

View Price & Availability

Performance

Watts	100W
Color Temp	5000K
Lumens	12,000 lm
Efficacy	120
Color Accuracy	80 CRI
L70 Lifespan	50,000 Hours

Input Voltage	120V
Power Factor	0.9
Flicker	30%
THDi	N/A

EZ-Layout

Create Custom Lighting Layout

Dimensions

Weight: 4.8 lbs

Technical Specifications

Performance

Product Type

LED Temporary String Light

Description

Upgrade traditional work lights with efficient, portable LED string lights.

Wattage Equivalency

300W Incandescent

Input Wattage

100W

Lumens

12,000lm

Efficacy

120lm/W

L70 Lifespan

50,000-Hour LED lifespan based on IES LM-70 results

Electrical

Driver

Constant Current

Power Factor

0.5

Dimmable

Input Voltage

120V

Operating Frequency

60 Hz

Input Current @ 120V (mA)

1,430mA

Operating Temperature

-40°F to 104°F (-40°C to -40°C)

Flicker

30%

Sensor Settings

Surge Protection

1kV

LED Characteristics

Beam Angle

120°

Color Temperature

5000K

Color Accuracy (CRI)

>80 CRI

Color Consistency

<7-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color

Installation

Mounting

Integrated hanging hook

Base Type

SPT-2W 18/2AWG power cord, high-impact design ANSI 2-prong plug and receptacle with weatherproof cover. No ground required; housing is made of polycarbonate material

Linkable

Linkable strands up to 400W

Construction

Lamp Shape

Oval lamp with frosted lens

Finish

Orange

Enclosure Material

Polycarbonate

Compliance

ETL Listed

This product has been tested by Intertek and found in compliance with accepted national standards.

Environment

Suitable for use indoors and outdoors in dry, damp, or wet environments.

Fixture Rating

Suitable for use in enclosed fixtures.
Suitable for use in open fixtures.

IP Rating

IP65

Energy Star Approved

DLC Listed

Certification Model Number

STRING17-100

California Title 20 Compliant

California Title 24 JA8 Compliant

California Energy Commission (CEC) Status

Lawful for Sales in California

NSF Listed

RoHS

Mercury and UV free. RoHS-compliant components.

FCC

Complies with Part 15 of the FCC Rules

Other

3 Yr Limited Warranty

The RAB 3-year, limited warranty covers light output, driver performance and paint finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty
