A17-4T300/480

Spec Sheet IES File LM79 Instructions Sell Sheet Folleto (Español) Family Spec Sheet Spec Sheet EZ Layout

A17-4T300/480

0-10V Dimming, standard

100,000-hour LED lifespan

5-Year, limited warranty

View Technical Specs

View Price & Availability

Performance

Watts	300/240/200W
Color Temp	3000/4000/5000K
Lumens	32,302-46,435 lm
Efficacy	144.3-165 lm/W
Color Accuracy	81-84 CRI
L70 Lifespan	100,000 Hours

Type	Constant Current
120V	/480
208V
240V
277V
Input Watts	208.4-301.8W

EZ-Layout

Create Custom Lighting Layout

Dimensions

Weight: 11.5 lbs

Technical Specifications

Compliance

UL Listed

Suitable for wet locations

IESNA LM-79 & LM-80 Testing

RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.

IP Rating

Ingress protection rating of IP65 for dust and water

DLC Listed

This product is listed by Design Lights Consortium (DLC) as an ultra-efficient premium product that qualifies for the highest tier of rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.
DLC Product Code: S-5KFGZ9 (Architectural Flood and Spot Luminaires)
DLC Product Code: S-GTYB8Z (Outdoor Pole/Arm-Mounted Area and Roadway Luminaires)

Electrical

Driver

300W: Constant Current, Class 1, 480V, 50/60 Hz, 480V: 0.64A
240W: Constant Current, Class 1, 480V, 50/60 Hz, 480V: 0.54A
200W: Constant Current, Class 1, 480V, 50/60 Hz, 480V: 0.45A

Dimming Driver

Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%.

THD

149.1% at 480V

Power Factor

96.2% at 480V

Surge Protection

6kV

Performance

Lifespan

100,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations

Construction

IES Classification

The Type IV distribution (also known as a Forward Throw) is especially suited for mounting on the sides of buildings and walls, and for illuminating the perimeter of parking areas. It produces a semicircular distribution with essentially the same candlepower at lateral angles from 90° to 270°.

Cold Weather Starting

The minimum starting temperature is -40°C (-40°F)

Maximum Ambient Temperature

Suitable for use in up to 40°C (104°F)

Lens

Polycarbonate lens

Housing

Die-cast aluminum housing, lens frame and mounting arm

Vibration Rating

3G vibration rating per ANSI C136.31

Effective Projected Area (Without Shield)

1 Fixture: 0.72 ft²
2 Fixtures at 90°: 1.04 ft²
2 Fixtures at 180°: 1.43 ft²
3 Fixtures at 90°: 1.76 ft²
4 Fixtures at 90°: 1.76 ft²

Effective Projected Area (With Shield)

1 Fixture: 0.75 ft²
2 Fixtures at 90°: 1.39 ft²
2 Fixtures at 180°: 1.5 ft²
3 Fixtures at 90°: 2.15 ft²
4 Fixtures at 90°: 2.15 ft²

Finish

Formulated for high durability and long-lasting color

Green Technology

Mercury and UV free. RoHS-compliant components.

LED Characteristics

LEDs

Long-life, high-efficiency, surface-mount LEDs

Color Uniformity

RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.

Installation

Mounting

Universal mounting arm compatible for hole spacing patterns from 1" to 5 1/2" center to center. Round Pole Adaptor plate included as a standard. Easy slide and lock to mount fixture with ease. Round pole diameter must be >4" to mount fixtures at 90° orientation.

Optical

BUG Rating

B5 U0 G5

Other

5-Year Limited Warranty

The RAB 5-year, limited warranty covers light output, driver performance and paint finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
