A19-13-E26-850-DIM

Spec Sheet Family Spec Sheet Spec Sheet

A19-13-E26-850-DIM

Energy-efficient replacement for incandescent and halogen lamps

Durable plastic construction reduces risk of breakage

Rated for use in enclosed and open fixtures in dry or damp locations

Frosted lens delivers smooth, diffuse light

Longer lifespan compared to legacy equivalents minimizes replacement and maintenance costs

View Technical Specs

View Price & Availability

Performance

Watts	11W
Color Temp	5000K
Lumens	1,100 lm
Efficacy	100
Color Accuracy	80 CRI CRI
L70 Lifespan

Type
120V
208V
240V
277V
Input Watts	11W

Dimensions

Weight: 0.1 lbs

Technical Specifications

Performance

Product Type

A-line, 80CRI Dimmable

Description

Classic A-line lamps that deliver the familiar incandescent look with smooth dimming and modern energy-saving performance.

Wattage Equivalency

75W Incandescent

Input Wattage

11W

Lumens (Nominal)

1,100lm

Efficacy

100lm/W

L70 Lifespan

15,000-Hour LED lifespan based on IES LM-70 results

Electrical

Driver

Constant Current 120V 50/60 Hz; 120V: 110mA

THD

<85%

Power Factor

0.7

Dimmable

Yes, dimmable down to 10% on compatible TRIAC/ELV dimming systems. See Dimmer Compatibility List.

Input Voltage

120V

Flicker

_85%

Construction

Operating Temperature Range

-4°F - 104°F (-20°C - 40°C)

Shape

A19

Finish

White

Endcap Material

Nickel-plated aluminum

Enclosure Material

Constructed from frosted, shatter-resistant polycarbonate

Lens Finish

Frosted

LED Characteristics

Beam Angle

160°

Color Temperature

5000K

Color Accuracy (CRI)

≥80 CRI

R9 Value

High color performance with R9 greater than 0

Color Consistency

<7-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color

Installation

Base Type

E26 Edison

Compliance

ETL Listed

This product has been tested by Intertek and found in compliance with accepted national standards.

Environment

Suitable for use indoors in dry and damp environments.

Fixture Rating

Suitable for use in enclosed fixtures

Energy Star Approved

DLC Listed

This product family is listed with the DesignLights Consortium (DLC). Individual SKUs within this family may carry either a DLC Standard or DLC Premium qualification. Please refer to the individual product specification sheet or the DLC Qualified Products List (QPL) at designlights.org to confirm the qualification status of a specific SKU prior to specification or purchase.

Certification Model Number

A30034(A19-13-E26-850-DIM)

California Title 20 Compliant

California Title 24 JA8 Compliant

California Energy Commission (CEC) Status

Lawful for Sales in California

RoHS

Mercury and UV free. RoHS-compliant components.

FCC

Complies with Part 15 of the FCC Rules

Other

3-Year, No-Compromise Warranty

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of three (3) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
