A19-15-E26-950-DIM

Spec Sheet Family Spec Sheet Spec Sheet

A19-15-E26-950-DIM

Energy-efficient replacement for incandescent and halogen lamps

Durable plastic construction reduces risk of breakage

Rated for use in enclosed and open fixtures in dry or damp locations

Frosted lens delivers smooth, diffuse light

Longer lifespan compared to legacy equivalents minimizes replacement and maintenance costs

View Technical Specs

View Price & Availability

Performance

Watts	15W
Color Temp	90 CRI
Lumens	1,600 lm
Efficacy	107
Color Accuracy
L70 Lifespan

Type
120V
208V
240V
277V
Input Watts	15W

Dimensions

Weight: 0.1 lbs

Technical Specifications

Performance

Product Type

A-line, 90CRI Dimmable Title 20 Compliant

Description

Exceptional color accuracy and smooth dimming come together in Title 20-compliant A-line LED lamps.

Wattage Equivalency

100W Incandescent

Input Wattage

15W

Lumens (Nominal)

1,600lm

Efficacy

107lm/W

L70 Lifespan

15,000-Hour LED lifespan based on IES LM-70 results

Electrical

Driver

Constant Current 120V 50/60 Hz; 120V: 135mA

THD

<30%

Power Factor

0.9

Dimmable

Yes, dimmable down to 10% on compatible TRIAC/ELV dimming systems. See Dimmer Compatibility List.

Input Voltage

120V

Flicker

<30%

Construction

Operating Temperature Range

-4°F - 104°F (-20°C - 40°C)

Shape

A19

Finish

White

Endcap Material

Nickel-plated aluminum

Enclosure Material

Constructed from frosted, shatter-resistant polycarbonate

Lens Finish

Frosted

LED Characteristics

Beam Angle

220°

Color Temperature

5000K

Color Accuracy (CRI)

≥90

R9 Value

High color performance with R9 greater than 50

Color Consistency

<4-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color

Installation

Base Type

E26 Edison

Compliance

ETL Listed

This product has been tested by Intertek and found in compliance with accepted national standards.

Environment

Suitable for use indoors in dry and damp environments.

Fixture Rating

Suitable for use in enclosed fixtures

Energy Star Approved

DLC Listed

Certification Model Number

A30056(A19-15-E26-950-DIM)

California Title 20 Compliant

Can be used to conform with the requirements of California Title 20

California Title 24 JA8 Compliant

California Energy Commission (CEC) Status

Lawful for Sales in California

IESNA LM-79 & LM-80 Testing

RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.

RoHS

Mercury and UV free. RoHS-compliant components.

FCC

Complies with Part 15 of the FCC Rules

Other

3-Year, No-Compromise Warranty

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of three (3) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
