A19-8.5-E26-850-ND 120-277V

Spec Sheet FCC Caution Spec Sheet

Energy efficient replacement for incandescent and halogen lamps

Constructed from durable plastic which lowers risk of breakage

Rated for use in enclosed and open fixtures in dry or damp locations

Frosted lens produces smooth diffuse light

Longer lifespan compared to legacy equivalents minimizes replacement and maintenance costs

ENERGY STAR Compliant

120V-277V Universal Voltage

View Technical Specs

View Price & Availability

Performance

Watts	8W
Color Temp	5000K
Lumens	840 lm
Efficacy	105
Color Accuracy	80 CRI
L70 Lifespan	25,000 Hours

Type	Constant Current
120V	0.09A
208V	0.05A
240V	0.04A
277V	0.03A
Input Watts	8W

Dimensions

Technical Specifications

Performance

Product Type

A-line Commercial Bulbs

Description

Ideal replacement for legacy HID or high output incandescent bulbs.

Wattage Equivalency

Equivalent to 60W Incandescent

Input Wattage

Lumens

840lm

Efficacy

105lm/W

L70 Lifespan

25,000-Hour LED lifespan based on IES LM-70 results

Electrical

Power Factor

>0.7

Dimmable

Dimming Type

Not suggested for dimming applications

Input Voltage

120-277V

Operating Frequency

50/60Hz

Operating Temperature

-4°F to 113°F (-20°C to 45°C)

LED Characteristics

Color Temperature

5000K

Color Accuracy (CRI)

>80 CRI

R9 Value

High color performance with R9 no less than 0

Color Consistency

<7-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color

Installation

Base Type

E26 Edison

Construction

Finish

White

Bulb Shape

A19

Enclosure Material

Plastic

Lens Finish

Frosted

Compliance

Listings

UL Listed, UL Classified

Fixture Rating

Suitable for use in enclosed fixtures

California Energy Commission (CEC) Status

Not Lawful for Sales in California

RoHS

Mercury and UV free. RoHS-compliant components.

FCC

Complies with Part 15B of the FCC Rules

Other

3-Year, No-Compromise Warranty

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of three (3) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
