RGBW Starter Kit

Starter Kit is the ideal introduction to Lightcloud Blue. Quick to install and easy to setup in minutes. No Gateway or Hub required.

The Kit includes:
(2) RGBW A19 lamps (LCBA19-9-E26-9RGB-SS)
(1) Remote (LCBLUEREMOTE/W)
(1) Nano (NANO/LCB)

60W Incandescent

8W (per lamp)

800lm (per lamp)

100lm/W (per lamp)

25,000-Hour LED lifespan based on IES LM-70 results (lamps only)

Lightcloud Blue is a Bluetooth mesh wireless lighting control system that allows you to control RAB's various compatible devices. With RAB's patent-pending Rapid Provisioning technology, devices can be quickly and easily commissioned for residential and large commercial applications using the Lightcloud Blue mobile app. Each device in a system can communicate with any other device, eliminating the need for a Gateway or Hub and maximizing the control system's reach.
DLC system - N1XMLOEATBA
Learn more at www.lightcloud.com

No

Bluetooth Mesh

SmartShift is the most advanced - yet easiest to use - circadian lighting system, which syncs white color tuning with the local sunrise and sunset.

Up to 60 feet between standard building materials.
Up to 200 feet clear line of sight.

The Nano must be connected to a 2.4 GHz Wi-Fi network. The Nano and the mobile device that it is pairing with must be on the same Wi-Fi network.

LCBLUEREMOTE/W
Wireless Remote can control up to 3 Areas (up to 600 devices)

NANO/LCB
Nano can manage up to 16 Areas or 600 devices

Method 1: Delete from App (all devices)
Open the app and access the device settings for the paired device. Be sure that the device is online and select 'Delete'. The device will flash on/off 5 times and return to full brightness.

Method 2a: Manual (lamps only)
Power the device off and on 5x consecutively. Do not allow less than 4s to elapse from switching off to on. Do not allow more than 2s to elapse from switching on to off. The device will flash 3x, then reset to 100% brightness at default CCT.

Method 2b Manual: (Remote)
Press and hold "On/Off" button and "Function 1" (..) buttons at the same time for 5 seconds until you see a slow flashing red light at the top left corner on the face of the Remote.

Method 2c Manual: (Nano)
Press and hold the center button on the Nano for 10 seconds. A flashing red light will appear to indicate the Nano has been reset and then revert to a flashing blue light indicating the Nano is ready to pair to the App.

Method 3: Rapid Reset Tool (lamps only)
The Rapid Reset process must be done by a professional electrician qualified by RAB. Reach out to your RAB sales manager to request a Rapid Reset Tool. The tool simply needs to be placed directly on the small Lightcloud Blue logo on the device for 2s or until the lamp/luminaire flashes 3x, then resets to 100% brightness at the default CCT.

≥0.9

Yes, via the Lightcloud Blue mobile app and devices.
This lamp will not operate properly when connected to a standard (incandescent) dimmer or dimming control.

RGBW A19 Lamp: 120V
Nano: 3V
Remote: 3V

RGBW A19 Lamp: 60Hz
Nano: DC
Remote: DC

75mA (lamps only)

-4°F to 113°F (-20°C to 45°C)

<30%

Remote: CR2032 (included)

2-years

Tunable White 2700K - 6500K 16+ million colors (lamps only)

>90 CRI

>0

<4-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color

Nano: Plugs into any compatible USB Type A port
Remote: Includes backplate, faceplate and mounting screws to replace a single gang wall box or to be installed on any flat surface.

RGBW A19 Lamp: E26
Nano: USB Type A

White

RGBW lamps: A19
Nano: Rectangular Cube
Remote: Rectangle

RGBW A19 Lamps: Plastic
Nano: Plastic
Remote: Plastic

Frosted

UL Listed

Suitable for use in dry and damp environments

Can be used to conform with the requirements of California Title 20

No

Complies with Part 15B of the FCC Rules

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of three (3) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.

All values are typical (tolerance +/- 10%)
