ALEDM4TSFYA/480

Spec Sheet IES File LM79 Instructions Spec Sheet EZ Layout

ALEDM4TSFYA/480

90W Amber

Wildlife-friendly amber light

0-10V dimmable standard

IP66 Rated

100,000-Hour LED lifespan

10-Year, No-Compromise Warranty

View Technical Specs

View Price & Availability

Performance

Watts	90/78W
Color Temp	Amber
Lumens	7,784/6,913 lm
Efficacy	85.0/92.9 lm/W
Color Accuracy
L70 Lifespan	100,000 Hours

Type	Constant Current
120V
208V
240V
277V
Input Watts	91.6/74.4W

EZ-Layout

Create Custom Lighting Layout

Dimensions

Weight: 17.8 lbs

Technical Specifications

Field Adjustability

Field Adjustable (Wattage)

Field adjustable light output in 2 discrete steps:
Medium Housing:90W/78W (factory default 90W)

Compliance

UL Listed

Suitable for wet locations

IP Rating

Ingress protection rating of IP66 for dust and water

IESNA LM-79 & LM-80 Testing

RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.

LED Characteristics

LEDs

Long-life, high-efficacy, discrete, surface-mount LEDs

Electrical

Driver

78W: Constant Current, Class 2, 480V, 50/60 Hz, 480V:0.20A

90W: Constant Current, Class 2, 480V, 50/60 Hz, 480V:0.23A

150W: Constant Current, Non-Class 2, 480V, 50/60 Hz, 480V: 0.32A

Dimming Driver

Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%.

THD

17.19% at 480V

Power Factor

89.9% at 480V

Surge Protection

Line to Line: 10kV
Line to Ground: 6kV

Performance

Lifespan

100,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations

Wattage Equivalency

Equivalent to 400W Metal Halide

Construction

IES Classification

The Type IV distribution is especially suited for mounting on the sides of buildings and walls, and for illuminating the perimeter of parking areas. It produces a semicircular distribution with essentially the same candlepower at lateral angles from 90° to 270°.

Cold Weather Starting

The minimum starting temperature is -40°C (-40°F)

Ambient Temperature

Max Power Temp Rating: 40°C (104°F)
Middle Power Temp Rating: 52°C (125°F)
Low Power Temp Rating: 54°C (130°F)

Housing

Die-cast aluminum

Mounting

2 3/8" slipfitter mount with stainless steel hardware

Tilt Increment

Rotates in 5 degree increments

Lens

Polycarbonate lens

Reflector

Aluminum reflector with white polycarbonate

Vibration Rating

3G vibration rating per ANSI C136.31

Gaskets

High-temperature silicone gaskets

Finish

Formulated for high durability and long-lasting color

Green Technology

Mercury and UV free. RoHS-compliant components.

Optical

Bug Rating

150W: B2 U0 G3
90W: B1 U0 G3
78W: B1 U0 G3

BUG Rating

90W: B1 U0 G3
78W: B1 U0 G3

Other

Warranty

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of ten (10) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.

Buy American Act Compliance

RAB values USA manufacturing! Upon request, RAB may be able to manufacture this product to be compliant with the Buy American Act (BAA). Please contact customer service to request a quote for the product to be made BAA compliant.
