ALEDMATWMYAB/480
ALEDMATWMYAB/480
90W Amber
- Wildlife-friendly amber light
- 0-10V dimmable standard
- IP66 Rated
- 100,000-Hour LED lifespan
- 10-Year, No-Compromise Warranty
Performance
| Watts | 90/78W |
| Color Temp | Amber |
| Lumens | 4,571/4,524 lm |
| Efficacy | 50.5/57.1 lm/W |
| Color Accuracy | |
| L70 Lifespan | 100,000 Hours |
| Type | Constant Current |
| 120V | |
| 208V | |
| 240V | |
| 277V | |
| Input Watts | 90.6/79.2W |
Dimensions
Weight: 16.5 lbs
Technical Specifications
Field Adjustability
Field Adjustable (Wattage)
Field adjustable light output in 2 discrete steps:
Medium Housing:90W/78W (factory default 90W)
Medium Housing:90W/78W (factory default 90W)
Compliance
UL Listed
Suitable for wet locations
IP Rating
Ingress protection rating of IP66 for dust and water
IESNA LM-79 & LM-80 Testing
RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
LED Characteristics
LEDs
Long-life, high-efficacy, discrete, surface-mount LEDs
Electrical
Driver
78W: Constant Current, Class 2, 480V, 50/60 Hz, 480V:0.20A
90W: Constant Current, Class 2, 480V, 50/60 Hz, 480V:0.23A
150W: Constant Current, Non-Class 2, 480V, 50/60 Hz, 480V: 0.32A
90W: Constant Current, Class 2, 480V, 50/60 Hz, 480V:0.23A
150W: Constant Current, Non-Class 2, 480V, 50/60 Hz, 480V: 0.32A
Dimming Driver
Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%.
Surge Protection
Line to Line: 10 kV
Line to Ground: 6 kV
Line to Ground: 6 kV
Performance
Lifespan
100,000-Hour LED lifespan based on IESlm-80 results and TM-21 calculations
Wattage Equivalency
Equivalent to 400W Metal Halide
Optical
IES Classification
Car Dealership optics have a wide distribution with an intentional hot spot that helps to deliver eye-catching light to the front row of cars in a dealership lot while also minimizing "backspill" (light that is thrown back towards the street).
Bug Rating
150W: B3 U0 G2
90W: B2 U0 G1
78W: B2 U0 G1
90W: B2 U0 G1
78W: B2 U0 G1
BUG Rating
90W: B1 U0 G1
78W: B1 U0 G1
78W: B1 U0 G1
Construction
Cold Weather Starting
The minimum starting temperature is -40°F (-40°C)
Ambient Temperature
Max Power Temp Rating: 104°F (40°C )
Middle Power Temp Rating: 52°C (125°F)
Low Power Temp Rating: 54°C (130°F)
Middle Power Temp Rating: 52°C (125°F)
Low Power Temp Rating: 54°C (130°F)
Housing
Die-cast aluminum
Lens
Polycarbonate lens
Reflector
Aluminum reflector with white polycarbonate
Vibration Rating
3G vibration rating per ANSI C136.31
Effective Projected Area (EPA)
EPA = 0.35
Gaskets
High-temperature silicone gaskets
Finish
Formulated for high durability and long-lasting color
Green Technology
Mercury and UV free. RoHS-compliant components.
Installation
Mounting
Wall mount
Other
10-Year, No-Compromise Warranty
RAB warrants that our LED products will be free from defects in materials and workmanship for a period of ten (10) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
