BAYLED78NW

Spec Sheet IES File Instructions Spec Sheet EZ Layout

BAYLED78NW

Replaces 250W MH high bays

Reduces energy consumption by 67%

100,000-hour LED lifespan

5-Year, No-Compromise Warranty

View Technical Specs

View Price & Availability

Performance

Watts	78W
Color Temp	4000K (Neutral)
Lumens	11,392 lm
Efficacy	125.3 lm/W
Color Accuracy	75 CRI
L70 Lifespan	100,000 Hours

Type	Constant Current
120V	0.82A
208V	0.52A
240V	0.45A
277V	0.4A
Input Watts	90.9W

EZ-Layout

Create Custom Lighting Layout

Dimensions

Weight: 26.5 lbs

Technical Specifications

Compliance

UL Listed

Suitable for damp locations with cord and hook. Suitable for wet locations with 3/4" pendant stem. Covered ceiling mount only.

IESNA LM-79 & LM-80 Testing

RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.

Trade Agreements Act Compliant

This product is a product of Cambodia and a "designated country" end product that complies with the Trade Agreements Act

DLC Listed

This product is on the Design Lights Consortium (DLC) Qualified Products List and is eligible for rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.
DLC Product Code: PGOUN6HF

LED Characteristics

LEDs

Three multi-chip, 26W high-output, long-life LEDs

Color Consistency

3-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color

Color Stability

LED color temperature is warrantied to shift no more than 200K in color temperature over a 5-year period

Color Uniformity

RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377.2011.

Performance

Lifespan

100,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations

Wattage Equivalency

Equivalent to 4 lamp T8 fixtures

Construction

Ambient Temperature

Suitable for use in up to 55°C (131°F)

Thermal Management

Superior thermal management with external air-flow fins

Housing

Precision die-cast aluminum housing and door frame with 3-foot 600V power cord

Lens

Tempered glass

Reflector

Specular vacuum metallized polycarbonate

Gaskets

High-temperature silicone

Finish

Formulated for high durability and long-lasting color

Green Technology

Mercury and UV free. RoHS-compliant components.

Installation

Mounting

Heavy-duty 3/4" NPS hook and 3 foot safety chain

Recommended Mounting Height

25 ft

Other

Patents

The design of the BAYLED™ is protected by patents pending in US, Canada, China, Taiwan and Mexico

Accessories

Available accessories include protective polyshield and wire guards, replacement lens and doorframe, and an occupancy sensor. Click here to see all accessories.

Warranty

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.

Electrical

THD

11.83% at 120V, 9.66% at 277V

Power Factor

99.1% at 120V, 93.5% at 277V

Drivers (3)

Constant Current, 720mA, Class 2 with 6kV surge protection, 100-277VAC, 50/60 Hz
