Patented base mount design for super sturdy installation
Durable construction and frosted vandal-resistant polycarbonate lens
4 configurations to provide 360°(24W), 270°(18W), 180°(12W) or 90°(12W) lighting pattern
Precision-engineered optics deliver maximum downward lighting without glare
Four leveling screws provided for easy installation
100,000-hour LED lifespan
View Technical Specs
Watts 12W
Color Temp 5100K (Cool)
Lumens 1,299
Efficacy 108 lm/W
Color Accuracy 74 CRI
L70 Lifespan 100,000 hours
Type Constant Current
120V 0.13A
208V 0.09A
240V 0.08A
277V 0.07A
Input Watts 12W

Weight: 21.8 lbs

Technical Specifications

UL Listing

Suitable for wet locations. Suitable for mounting within 4 ft. (1.2m) of the ground.

DLC Listed

This product is on the Design Lights Consortium (DLC) Qualified Products List and is eligible for rebates from DLC Member Utilities.
DLC Product Code: P00001721

IESNA LM-79 & IESNA LM-80 Testing

RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.

LED Characteristics


Long-life, high-efficiency, surface mount LEDs


100,000-hour LED lifespan based on IES LM-80 results and TM-21 calculations

Color Consistency

5-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color

Color Stability

LED color temperature is warrantied to shift no more than 200K in CCT over a 5 year period

Color Uniformity

RAB's range of CCT (Correlated Color Temperature) follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017



Constant Current, Class2, 100-277V, 50/60 Hz, 4kV Surge Protection, 700mA, 120V: 0.13A, 208V: 0.09A, 240V: 0.08A, 277V: 0.07A


11.7% at 120V, 21.9% at 277V

Power Factor

97.8% at 120V, 90% at 277V


BUG Rating

B1 U3 G1


Cold Weather Starting

Minimum starting temperature is -40°C (-40°F)

Thermal Management

Cast aluminum Thermal Management system for optimal heat sinking. The BLED is designed for cool operation, maximum efficiency and long life by minimizing LED junction temperature.


Die-cast aluminum with extruded aluminum post


Frosted vandal resistant polycarbonate


Vacuum metalized polycarbonate


Four (4) anchor bolts provided for concrete pad mounting. Internal base support has leveling screws.


High-temperature silicone gaskets seal out moisture gaskets seal out moisture

Anchor Bolt

Anchor Bolt Dimension is available here.


Our environmentally friendly polyester powder coatings are formulated for high-durability and long-lasting color

Green Technology

Mercury and UV-free. RoHS compliant components.



The design of BLED is protected by patents in US, Canada & China


RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at
