BLEDR12-180-32H/D10
BLEDR12-180-32H/D10 large main
  • Patented base mount design for super sturdy installation
  • Durable construction and frosted vandal-resistant polycarbonate lens
  • 4 configurations to provide 360°(24W), 270°(18W), 180°(12W) or 90°(12W) lighting pattern
  • Precision-engineered optics deliver maximum downward lighting without glare
  • Four leveling screws provided for easy installation
  • 100,000-hour LED lifespan
 View Technical Specs
View Price & Availability
Performance
Watts 12W
Color Temp 5000K (Cool)
Lumens 1,308 lm
Efficacy 108.1 lm/W
Color Accuracy 74 CRI
L70 Lifespan 100,000 Hours
Type Constant Current
120V 0.13A
208V 0.09A
240V 0.08A
277V 0.07A
Input Watts 12.1W
Dimensions
Link to Dimension Drawing

Weight: 18.6 lbs

Technical Specifications
Compliance
UL Listed
Suitable for wet locations. Suitable for mounting within 4 ft (1.2m) of the ground.
LED Characteristics
LEDs
Long-life, high-efficiency, surface-mount LEDs
Performance
Lifespan
100,000-Hour LED lifespan based on IESlm-80 results and TM-21 calculations
Optical
BUG Rating
B1 U3 G1
Construction
Height
32"
Cold Weather Starting
The minimum starting temperature is -40°F (-40°C)
Electrical
Driver
Constant Current, Class2, 100-277V, 50/60 Hz, 4kV Surge Protection, 700mA, 120V: 0.13A, 208V: 0.09A, 240V: 0.08A, 277V: 0.07A
THD
11.7% at 120V, 22.6% at 277V
Power Factor
98.3% at 120V, 89% at 277V
