20W 3000K/4000K/5000K
  • 100,000-hour LED Life
  • On/Off photocell
  • 5-Year, limited warranty
View Technical Specs
Performance
Watts 20/16/12W
Color Temp 3000K/4000K/5000K
Lumens 1,174-2,043 lm
Efficacy 93.1-115.7 lm/W
Color Accuracy 82-84 CRI
L70 Lifespan 100,000 Hours
Type Constant Current
120V 0.20A/0.15A/0.10A
208V 0.10A/0.08A/0.06A
240V 0.09A/0.07A/0.06A
277V 0.08A/0.07A/0.05A
Input Watts 11.18-19.32W
Dimensions
Link to Dimension Drawing

Weight: 3.3 lbs

Technical Specifications
Field Adjustability
Field Adjustable
Field Adjustable Light Output:
20W/16W/12W (factory default 20W)
Color Temperature Selectable:
3000K, 4000K and 5000K (factory default 5000K)
On/Off Photocell (factory default "On")
Performance
Lifespan
100,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations
LED Characteristics
LEDs
Long-life, high-efficacy, discrete, surface-mount LEDs
Electrical
Driver
Constant Current, Class 1, 120-277V, 50/60 Hz:
20W: 0.20A, 208V: 0.10A, 240V: 0.09A, 277V: 0.08A
16W: 120V: 0.15A, 208V: 0.08A, 240V: 0.07A, 277V: 0.07A
12W: 120V: 0.10A, 208V: 0.06A, 240V: 0.06A, 277V: 0.05A
THD
20W: 17.7% at 120V, 13.7% at 277V
16W: 17.9% at 120V, 13.7% at 277V
12W: 16.5% at 120V, 12.1% at 277V
Power Factor
20W: 98.5% at 120V, 93.8% at 277V
16W: 98.4% at 120V, 91.7% at 277V
12W: 98.3% at 120V, 87.4% at 277V
Aux Power Supply
No
Dim to Off
No
Photocell
120-277V selectable photocell that can be turned on and off.
Surge Protection
2kV
Construction
Cold Weather Starting
The minimum starting temperature is -40°C (-40°F)
Ambient Temperature
Suitable for use in up to 45°C (113°F)
Housing
Die-cast aluminum
Lens
Glass
Gaskets
High-temperature silicone
Finish
Formulated for high durability and long-lasting color
Green Technology
Mercury and UV free. RoHS-compliant components.
Compliance
UL Listed
Suitable for wet locations
IESNA LM-79 & LM-80 Testing
RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
IP Rating
Ingress protection rating of IP65 for dust and water
Installation
Mounting
Wall mount
Optical
BUG Rating
20W: B1 U3 G1
16W: B1 U3 G1
12W: B1 U3 G1
Other
5 Yr Limited Warranty
The RAB 5-year, limited warranty covers light output, driver performance and paint finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
