• Easy, secure floodlight mounting
  • Double Reinforced weld joints
View Technical Specs
Dimensions
Link to Dimension Drawing

Weight: 44.0 lbs

Technical Specifications
Construction
Grade B Steel
A500 Grade B steel tubing
EPA
2.6
Weight
44 lbs
Pipe Size
2"
Tenon Outside Diameter
2 3/8"
Pole/Tenon Size
2 3/8"
Vertical
13"
Spacing
30"
Number of Lights
4
Finish
Formulated for high durability and long-lasting color
