30W 3500/4000/5000K
  • 0-10V Dimming, standard
  • 100,000-hour LED lifespan
  • 5-Year, no-compromise warranty
View Technical Specs
Performance
Watts 30/25/20W
Color Temp 3500/4000/5000K
Lumens 2,606-3,955 lm
Efficacy 130.9-138.4 lm/W
Color Accuracy 83-85 CRI
L70 Lifespan 100,000 Hours
Type Constant Current
120V 0.25A/0.21A/0.17A
208V 0.14A/0.12A/0.10A
240V 0.13A/0.10A/0.08A
277V 0.11A/0.09A/0.07A
Input Watts 19.3-29.3W
Dimensions
Link to Dimension Drawing

Weight: 7.5 lbs

Technical Specifications
Field Adjustability
Field Adjustable
Field Adjustable Light Output:
2' x 2': 30W/25W/20W (factory default 30W)
Color temperature selectable by 3500K, 4000K and 5000K (factory default 4000K)
Compliance
UL Listed
Suitable for damp locations
IESNA LM-79 & LM-80 Testing
RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
DLC Listed
This product is on the Design Lights Consortium (DLC) Qualified Products List and is eligible for rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.
DLC Product Code: S-TS7VFW
Electrical
Driver
30W: Class 2, Constant Current, 120-277V, 50/60 Hz, 120V: 0.25A, 208V: 0.14A, 240V: 0.13A, 277V: 0.11A
25W: Class 2, Constant Current, 120-277V, 50/60 Hz, 120V: 0.21A, 208V: 0.12A, 240V: 0.10A, 277V: 0.09A
20W: Class 2, Constant Current, 120-277V, 50/60 Hz, 120V: 0.17A, 208V: 0.10A, 240V: 0.08A, 277V: 0.07A
Dimming Driver
Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%.
THD
7.14% at 120V, 13.09% at 277V
Power Factor
99.7% at 120V, 95.2% at 277V
Surge Protection
L-N: 1KV
L/N-PE: 2KV
Battery Backup
Battery backup will operate the fixture for 90 minutes if power fails. Wired for 120-277V.
Battery Backup Light Loss Factor
30W: 14.7%
25W: 18%
20W: 22%
Construction
Cold Weather Starting
Minimum starting temperature is 5°C (41°F)
Ambient Temperature
Suitable for use in up to 40°C (104°F)
IC Rated
Suitable for direct contact with insulation
Housing
Polypropylene (PP)
Reflector
Integral reflector (on the sides) with high reflectance finish, optimized for uniform distribution.
Lens
Polycarbonate lens
Finish
Formulated for high durability and long-lasting color
Green Technology
Mercury and UV free. RoHS-compliant components.
Installation
Mounting
Recessed ceiling
LED Characteristics
LEDs
Long-life, high-efficacy, surface-mount LEDs
Color Stability
LED color temperature is warrantied to shift no more than 200K in color temperature over a 5-year period
Color Uniformity
RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.
Performance
Lifespan
100,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations
Other
5-Year, No-Compromise Warranty
RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
