• Direct Connect to the Lightcloud Blue mobile app via Bluetooth, no Gateway or Hub required
  • Use mobile device to configure features for On/Off Control, Dim Level, Schedules, Scenes, and more.
  • Meets Luminaire Level Lighting Control (LLLC) requirements
  • Integrated passive infrared or microwave sensor for added savings
  • Use mobile device to configure sensor settings for sensitivity, timeout and actions.
  • Field adjustable color temperature options between 3500K, 4000K, and 5000K
  • Emergency battery backup options available
View Technical Specs
Performance
Watts 30W
Color Temp Field Adjustable
Lumens 3117-4802 lm
Efficacy 106.6-127.5 lm/W
Color Accuracy 79-81 CRI
L70 Lifespan 75,000 Hours
Type Constant Current
120V 0.25A
208V 0.15A
240V 0.13A
277V 0.12A
Input Watts 25.7-41.5W
Dimensions
Link to Dimension Drawing

Weight: 8.2 lbs

Technical Specifications
Field Adjustability
Field Adjustable
Field Adjustable Light Output:
2' x 2': 40W/30W/25W (factory default 30W)
Color temperature selectable by 3500K, 4000K and 5000K (factory default 4000K)
Compliance
UL Listed
Suitable for damp locations
IESNA LM-79 & LM-80 Testing
RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
CCEA Compliant
Luminaire Requirements used in Environmental Air Space per the electrical code specification of the City of Chicago
Trade Agreements Act Compliant
This product is a product of Cambodia and a "designated country" end product that complies with the Trade Agreements Act
Performance
Lifespan
75,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations
LED Characteristics
LEDs
Edge-lit design with long-life, high-efficacy LEDs
Construction
Operating Temperature
-30°C (-22°F) to 40°C (104°F)
Lens
Frosted polystyrene
IC Rated
Suitable for insulated ceilings
Housing
Lightweight aluminum housing
Finish
Formulated for high durability and long-lasting color
Green Technology
Mercury and UV free. RoHS-compliant components.
Installation
Mounting
Recessed ceiling
Lightcloud
Lightcloud Blue Installed
Lightcloud Blue is a Bluetooth Mesh wireless lighting control system that allows you to control RAB's various compatible devices. With RAB's patented Rapid Provisioning technology, devices can be quickly and easily commissioned for residential and large commercial applications using the Lightcloud Blue mobile app. Each device in a system can communicate with any other device, eliminating the need for a Gateway or Hub and maximizing the control system's reach.

DLC system - N1XMLOEATBA (Interior); NHCZ2BIA17L (Exterior)

Learn more at www.lightcloud.com.
Other
Warranty
RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
Electrical
Driver
Constant Current, Class 2, 120-277V, 50/60 Hz, 120V: 0.25A, 208V: 0.15A, 240V: 0.13A, 277V: 0.12A
THD
5.8% at 120V, 11.03% at 277V
Power Factor
99.4% at 120V, 92.3% at 277V
