Integrated/embedded networked lighting control, luminaire-level lighting control. Fixture, Zone, and plug-load control from one powerful device. LLLC - capable of switching, 0-10Vdimming, power/energy monitoring. Can also be used to extend the range of the Lightcloud mesh network communication protocols. Offers the capability to set the maximum light output to a less-than-maximum state of an individual luminaire at the time of installation or commissioning. The High-End trim functionality is field reconfigurable via the Lightcloud mesh network communication protocols. The Lightcloud controller can be attached to the fixture, junction box, or electrical panel.
DLC system - NHCZ2BIA17L
Learn more at www.lightcloud.com

Suitable for wet locations. Suitable for mounting within 4 ft (1.2m) of the ground.

RAB LED luminaires have been tested by an independent laboratory in accordance with IESNAlm-79 andlm-80

Ingress protection rating of IP66 for dust and water

Constant Current, Class 1, 480, 50/60 Hz, 480V: 1.08A

9.12% at 480V

10 kV

NEMA Beam Spread 4H x 6V

100,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations

Equivalent to 1,500W Metal Halide

Multip-chip, high-output, long-life LEDs

LED color temperature is warrantied to shift no more than 200K in color temperature over a 5-year period

RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.

2G vibration rating per ANSI C136.31

The minimum starting temperature is -40°F (-40°C)

Suitable for use in up to 104°F (40°C)

EPA = 4

Superior thermal management with external "Air-Flow" fins

Die-cast aluminum housing with lens frame

Specular vacuum-metalized polycarbonate; semi-specular on flat trim edge

Clear glass lens

High-temperature silicone gaskets

Formulated for high durability and long-lasting color

Mercury and UV free. RoHS-compliant components.

Heavy-duty Trunnion mount with stainless steel hardware

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
