GUSJR4/PIR

Spec Sheet IES File LM79 Instructions Sell Sheet Family Spec Sheet Spec Sheet EZ Layout

GUSJR4/PIR

40W 3500K/4000K/5000K

Affordable, easy to use LED wrap fixture

0-10V dimming, standard

50,000-Hour LED lifespan

View Technical Specs

View Price & Availability

Performance

Watts	40/30/20W
Color Temp	3500K/4000K/5000K
Lumens	2,883-5,540 lm
Efficacy	127.7-150.1 lm/W
Color Accuracy	83-85 CRI
L70 Lifespan

Type	Constant
120V	0.36A/0.27A0.18A
208V	0.21A/0.16A/0.11A
240V	0.18A/0.14A/0.10A
277V	0.16A0.12A/0.09A
Input Watts	20.4-39.5W

EZ-Layout

Create Custom Lighting Layout

Dimensions

Weight: 10.1 lbs

Technical Specifications

Field Adjustability

Field Adjustable

Field Adjustable Light Output:
4ft: 44W/33W/22W (factory default 44W)
Color temperature selectable by 3500K, 4000K and 5000K (factory default 4000K)

Compliance

UL Listed

Suitable for damp locations

IESNA LM-79 & LM-80 Testing

RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.

Trade Agreements Act Compliant

This product is a product of Cambodia and a "designated country" end product that complies with the Trade Agreements Act

DLC Listed

This product is on the Design Lights Consortium (DLC) Qualified Products List and is eligible for rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.
DLC Product Code: S-QT24X6

Electrical

Driver

40W: Class 1, Constant Current, 120-277V, 50/60 Hz, 120V: 0.36A, 208V: 0.21A, 240V: 0.18A, 277V: 0.16A

30W: Class 1, Constant Current, 120-277V, 50/60 Hz, 120V: 0.27A, 208V: 0.16A, 240V: 0.14A, 277V: 0.12A

20W: Class 1, Constant Current, 120-277V, 50/60 Hz, 120V: 0.18A, 208V: 0.11A, 240V: 0.10A, 277V: 0.09A

Dimming Driver

Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%.

THD

8% at 120V, 7% at 277V

Power Factor

99.1% at 120V, 95.9% at 277V

Surge Protection

L-N: 2KV
L/N-GND: 4KV

Performance

Lifespan

50,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations

LED Characteristics

LEDs

Long-life, high-efficiency, surface-mount LEDs

Color Uniformity

RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.

Construction

Cold Weather Starting

The minimum starting temperature is -20°C (-4°F)

Maximum Ambient Temperature

Suitable for use in up to 45°C (113°F)

Housing

Sheet metal stamping 24 gauge, cold-rolled steel

Reflector

Sheet metal forming 24 gauge, cold-rolled steel with white powder coat

Lens

Diffused Polymethyl Methacrylate (PMMA)

Mounting

Surface mount. Can be mounted with v-hooks (ordered separately).

Finish

Formulated for high durability and long-lasting color

Green Technology

Mercury and UV free. RoHS-compliant components.

Sensor Specifications

PIR Sensor Factory Settings

Brightness: 100%
Hold Time: 1 Minute
Daylight: Disabled
Senstivity: 100%
Stand-By Dimming Level: 20%
Stand-By Time: 1 Minute

Operating Voltage

12 ± 2V DC

Operating Current

30mA

Output

DIM 0-10V

Stand-By Power

<0.5W

Brightness

0%-100%/Quick setting: 70%/80%/90%/100%

Hold Time

10s/1min/10min/30min

Daylight Threshold

10Lux/30Lux/50Lux/100Lux/Disable

Lux On-Off

Adopted dual PD technology. H17-PIR is able to differenciate artificial light brightness from natural light after installed inside.

Stand-By Time

1min/30min/60min/+∞

Stand-By Dimming Level

10%/20%/30%/50%

Detection Angle

≤120° (wall mounted) 360° (ceiling mounted)

Control Line

Black White 12V+ ; Purple: DIM+ ; Pink GND/DIM-

Mounting Height

Max 6M (ceiling mounted)

Detection Range

Max 8m (ceiling mounted) Max 6m(wall mounted)

Operating Temperature

-30°C to 60°C (-22°F to 140°F)

Other

5 Yr Limited Warranty

The RAB 5-year, limited warranty covers light output, driver performance and paint finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.

Buy American Act Compliance

RAB values USA manufacturing! Upon request, RAB may be able to manufacture this product to be compliant with the Buy American Act (BAA). Please contact customer service to request a quote for the product to be made BAA compliant.
