HAZXL34-120/480
HAZXL34-120/480
- Class 1, Division 1, Groups C, D
- IP66,UL 844, UL1598, UL 1598A and UL8750 ratings
- DLC Listed
- 100,000-Hour LED lifespan
- 5-Year, no-compromise warranty
Performance
| Watts | 120W |
| Color Temp | 5000K |
| Lumens | 17,618 lm |
| Efficacy | 145.3 |
| Color Accuracy | 82 CRI |
| L70 Lifespan | 100,000 Hours |
| Type | Constant Current |
| 120V | |
| 208V | |
| 240V | |
| 277V | |
| Input Watts | 121.3W |
Dimensions
Weight: 48.9 lbs
Technical Specifications
Hazardous Location Classifications
Class 1, Division 1 (Groups C, D)
Class 1 (Hazardous Material in Surrounding Atmosphere):
Flammable vapors or gases may be present
Division 1 (Presence of Hazardous Materials):
Ignitable concentrations of hazards exist only under normal operating conditions
Groups C, D (Hazardous Material in Surrounding Atmosphere):
C = Ethylene, cyclopropane and ethyl ether
D = Acetone, ammonia, benzene, butane, ethanol, gasoline, hexane, methane, methanol, naphta, natural gas, propane & toluene
Flammable vapors or gases may be present
Division 1 (Presence of Hazardous Materials):
Ignitable concentrations of hazards exist only under normal operating conditions
Groups C, D (Hazardous Material in Surrounding Atmosphere):
C = Ethylene, cyclopropane and ethyl ether
D = Acetone, ammonia, benzene, butane, ethanol, gasoline, hexane, methane, methanol, naphta, natural gas, propane & toluene
NEC/CE T-Code (Class 1, Div 1, Group C,D)
T6
UL 844
Electric lighting fixtures for use in hazardous (classified) locations
UL 1598
Electric lighting fixtures for use in non-hazardous locations
UL 1598A
UL 1598A includes requirements for materials that can withstand exposure to saltwater, humidity, and other corrosive elements.
UL 8750
Light Emitting Diode (LED) Light Sources for Use in Lighting Products
Compliance
UL Listed
Suitable for wet locations
IP Rating
Ingress protection rating of IP66 for dust and water
DLC Listed
This product is on the Design Lights Consortium (DLC) Qualified Products List and is eligible for rebates from DLC Member Utilities.
DLC Product Code: S-P93GDT
DLC Product Code: S-P93GDT
Electrical
Driver
Constant Current, Class1, Class P, 50/60 Hz, 480V, 480V: 0.29A
Dimming Driver
Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%.
THD
3.06% at 480V
Power Factor
94.6% at 480V
Aux Power Supply
No
Dim to Off
Yes
Surge Protection
L-N: 6 kV
L/N-PE: 10 kV
L/N-PE: 10 kV
LED Characteristics
LEDs
Long-life, high-efficacy, surface-mount LEDs
Color Stability
LED color temperature is warrantied to Shift no more than 200K in color temperature over a 5-year period
Color Uniformity
RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.
Construction
Rated Ambient Temperature Range
-40°F (-40°C) to 140°F (60°C), T4A
Housing
Die-cast aluminum
Tilt Increment
25.7 degree increments (yoke bracket)
Gaskets
High-temperature silicone
Green Technology
Mercury and UV free. RoHS-compliant components.
IK Rating
IK09 Protected against 10 joules impact. Equivalent to impact of 5kg mass dropped from 200mm above impacted surface.
Lens
Tempered glass
Reflector
White polycarbonate
Effective Projected Area
3.02 ft²
Finish
Formulated for high durability and long-lasting color
Performance
Lifespan
100,000-Hour LED lifespan based on IESlm-80 results and TM-21 calculations
Installation
Mounting
All models come standard with three mounting options: pendant
mount (pendant by others), chain mount, and a yoke bracket for surface
mount. A separate kit is available for ceiling mount.
Other
5-Year, No-Compromise Warranty
RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
