HIDFA-36S-E26-8CCT-BYP/5SP

Spec Sheet IES File Sensor Compatibility List LM79 Instructions Sell Sheet Family Spec Sheet Spec Sheet EZ Layout

Replaces traditional metal halide or high pressure sodium HID lamp

Adjustable wattage and CCT allows for in-field customization

Integral driver enables lamp to be wired directly to line voltage without need for an external driver or ballast

Rated for use in enclosed fixtures in dry or damp locations

View Technical Specs

View Price & Availability

Performance

Watts	36/27/18W
Color Temp	3000/4000/5000K
Lumens	2,430-5,220 lm
Efficacy	135-145 lm/W
Color Accuracy	80 CRI
L70 Lifespan	50,000 Hours

Type	Constant Current
120V	0.31A
208V	0.18A
240V	0.16A
277V	0.13A
Input Watts	36/27/18W

EZ-Layout

Create Custom Lighting Layout

Dimensions

Technical Specifications

Performance

Description

Field adjustable lumen output and CCT provide installation flexibility when replacing traditional HID. Integrated AUX port to add lamp-level sensor control.

Wattage Equivalency

75W/125W/150W Metal Halide

Input Wattage

18W/27W/36W

Lumens

18W:
3000K @ 2,430lm; 4000K @ 2,610lm; 5000K @ 2,520lm
27W:
3000K @ 3,645lm; 4000K @ 3,915lm; 5000K @ 3,780lm
36W:
3000K @ 4,860lm; 4000K @ 5,220lm; 5000K @ 5,040lm

Efficacy

18W/27W/36W:
3000K @ 135lm/W; 4000K @ 145lm/W; 5000K @ 140lm/W

L70 Lifespan

50,000-Hour LED lifespan based on IES LM-70 results

Electrical

THD

≤20%

Power Factor

≥0.9

Dimmable

Yes, via the Lightcloud Blue mobile app and devices.
This lamp will not operate properly when connected to a standard (incandescent) dimmer or dimming control.

Input Voltage

100-277V

Operating Frequency

50/60Hz

Input Current @ 120V (mA)

309mA

Input Current @ 208V (mA)

184mA

Input Current @ 240V (mA)

163mA

Input Current @ 277V (mA)

133mA

Operating Temperature

-22°F to 140°F (-30°C to 60°C)

Flicker

<30%

Surge Protection

4 kV

LED Characteristics

Color Temperature

Field adjustable via dip switch 3000/4000/5000K

Color Accuracy (CRI)

≥80 CRI

R9 Value

High color performance with R9 no less than 0

Color Consistency

<6-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color

Color Stability

LED color temperature is warrantied to Shift no more than 200K in color temperature over a 5-year period

Color Uniformity

RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.

Installation

Installation Method

UL Type B, Ballast Bypass

Installation Orientation

Vertical and Horizontal

Base Type

E26 Edison

Construction

Finish

Clear

Shape

Post top (sensor)

Endcap Material

Metal

Enclosure Material

Constructed from frosted, shatter-resistant polycarbonate

Compliance

Listings

UL Listed, UL Classified

Environment

Suitable for use in dry and damp environments

Fixture Rating

Suitable for use in enclosed fixtures

IP Rating

IP64

California Energy Commission (CEC) Status

Lawful for Sales in California

RoHS

Mercury and UV free. RoHS-compliant components.

FCC

Complies with Part 15B of the FCC Rules

Other

Compatible Products

Add the Lightcloud Blue 5-Pin Plug-in Controller with optional sensor to connect to the Lightcloud Blue Bluetooth Mesh Wireless Network Lighting Control System. Learn more about Lightcloud Blue.

Accessories

CONTROL/W/AUX/5SP/LCB
Lightcloud Blue 5-Pin Plug-in Controller
CONTROL/W/AUX/5SP/LCBS
Lightcloud Blue 5-Pin Plug-in Controller with PIR Sensor
CONTROL/W/AUX/5SP/LCBS/MVS
Lightcloud Blue 5-Pin Plug-in Controller with MVS Sensor

5-Year, No-Compromise Warranty

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
