LCBA19-9-E26-9RGB-SS

Spec Sheet IES File LM79 Instructions Sell Sheet Family Spec Sheet Spec Sheet EZ Layout

Replacement for legacy incandescent and halogen lamps

Direct Connect to the Lightcloud Blue mobile app via Bluetooth, no Gateway or Hub required

Use mobile device to configure features for On/Off Control, Dim Level, Color Temperature, Schedules, Scenes, SmartShift and more

Choose between 16+ million colors to fit any mood

Tunable White 2200-6500K with smooth transition between color temperatures

View Technical Specs

View Price & Availability

Performance

Watts	8W
Color Temp	Tunable White 2200K-6500K (16+ million colors)
Lumens	800 lm
Efficacy	100
Color Accuracy	90 CRI
L70 Lifespan	25,000 Hours

Type	Constant Current
120V	.075A
208V
240V
277V
Input Watts	8W

EZ-Layout

Create Custom Lighting Layout

Dimensions

Weight: 0.1 lbs

Technical Specifications

Lightcloud

Lightcloud Blue

Lightcloud Blue is a Bluetooth Mesh wireless lighting control system that allows you to control RAB's various compatible devices. With RAB's patented Rapid Provisioning technology, devices can be quickly and easily commissioned for residential and large commercial applications using the Lightcloud Blue mobile app. Each device in a system can communicate with any other device, eliminating the need for a Gateway or Hub and maximizing the control system's reach.

DLC system - N1XMLOEATBA (Interior); NHCZ2BIA17L (Exterior)

Learn more at www.rablighting.com/feature/new-lightcloud-blue.

Gateway Required

Communication Protocol

Bluetooth Mesh

SmartShift

SmartShift is the most advanced - yet easiest to use - circadian lighting system, which syncs white color tuning with the local sunrise and sunset.

Range

Up to 60 ft between standard building materials.
Up to 200 ft clear line of sight.

Performance

Product Type

A-Line

Input Wattage

Lumens

800lm

Efficacy

100lm/W

L70 Lifespan

25,000-Hour LED lifespan based on IES LM-70 results

Wattage Equivalency

Equivalent to 60W Incandescent

Electrical

Power Factor

≥0.9

Dimmable

Yes, via the Lightcloud Blue mobile app and devices

Input Voltage

120V

Operating Frequency

60Hz

Operating Temperature

-4°F to 113°F (-20°C to 45°C)

Flicker

<30%

Color Temperature

Tunable White 2200K - 6500K (16+ million colors)

LED Characteristics

Color Accuracy (CRI)

>90 CRI

R9 Value

High color performance with R9 no less than 0

Color Consistency

<4-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color

Installation

Base Type

E26 Edison

Construction

Finish

White

Bulb Shape

A19

Enclosure Material

Plastic package aluminum

Lens

Frosted lens for smooth, evenly diffused illumination

Compliance

Listings

UL Listed

Environment

Suitable for use in dry and damp environments

Fixture Rating

Suitable for use in open and enclosed fixtures

Energy Star ID

2401212

T20 Compliant

Can be used to conform with the requirements of California Title 20

California Energy Commission (CEC) Status

Lawful for Sales in California

RoHS

Mercury and UV free. RoHS-compliant components.

FCC

Complies with Part 15B of the FCC Rules

Other

3-Year, No-Compromise Warranty

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of three (3) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.

Accessories

LCBLUEREMOTE/W (Wireless Remote Control)
NANO/LCB(Nano Timekeeper & Web Access)
SENSE/PIR/W/LCB (Wireless Wall Sensor)
