LCBB11-5-E26-9TW-F-C-SS

Spec Sheet Instructions Spec Sheet

Direct Connect to the Lightcloud Blue mobile app via Bluetooth, no Gateway or Hub required

Use mobile device to configure features for On/Off Control, Dim Level, Color Temperature, Schedules, Scenes, SmartShift and more.

Tunable White 2200-4500K with smooth transition between color temperatures

Circadian SmartShift Capable to sync with local sunrise/sunset

Suitable for open or enclosed fixtures in dry, damp, or wet environments.

Title 20 Compliant, ENERGY STAR® compliant, UL Listed

View Technical Specs

View Price & Availability

Performance

Watts	5W
Color Temp	2200K-4500K
Lumens	500 lm
Efficacy	133
Color Accuracy	90 CRI
L70 Lifespan	15,000 Hours

Type	Constant Current
120V	0.06A
208V
240V
277V
Input Watts	5W

Dimensions

Weight: 0.1 lbs

Technical Specifications

Performance

Product Type

Bluetooth-Enabled Filaments

Input Wattage

Lumens

500lm

Efficacy

133lm/W

Lifespan

15,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations

LED Characteristics

Color Accuracy (CRI)

>90 CRI

Color Temperature

2200K-4500K

Electrical

Power Factor

0.7

Dimming

Dimmable via Lightcloud Blue mobile app

Flicker

<30%

Operating Temperature

-20℃C to 45℃C (-4℃F to 113℃F)

Input Voltage

120V

Operating Frequency

60Hz

Construction

Material

Glass

Bulb Shape

B11

Base Type

E26, Medium Screw Base

Optical

Beam Angle

360°

Compliance

UL Listed

Suitable for wet locations

Fixture Rating

Enclosed

Other

Warranty

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of three (3) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.

Buy American Act Compliance

RAB values USA manufacturing! Upon request, RAB may be able to manufacture this product to be compliant with the Buy American Act (BAA). Please contact customer service to request a quote for the product to be made BAA compliant.
