• Rugged die cast aluminum housing with polyester powder coat finish
  • Deep Glare Shield
  • weatherproof lens and gasket
  • "O" Ring seal for full weather protection
  • No-rust brass & stainless steel external hardware
  • Rugged mounting arm has 1/2" threads and pivots 180
  • EZ Grip locknuts are color matched to fixture and can be tightened with fingers, pliers or screwdriver
View Technical Specs
Performance
Watts 60W
Color Temp
Lumens 650 lm
Efficacy
Color Accuracy
L70 Lifespan
Type
120V
208V
240V
277V
Input Watts
Dimensions
Link to Dimension Drawing

Weight: 0.9 lbs

Technical Specifications
Compliance
UL Listed
Suitable for wet locations. Suitable for mounting within 4 ft (1.2m) of the ground.
Trade Agreements Act Compliant
This product is a product of Cambodia and a "designated country" end product that complies with the Trade Agreements Act
Construction
Swivels
1/2" NPS threaded arm with serrated locking swivel fits all standard mounting boxes. EZ Grip locknuts color matched to fixture.
Housings
Precision die-cast aluminum
Other
Compatibility
Fixture is compatible with GE and Sylvania Par16 lamps. Not compatible with Philips Par16 lamp.
Electrical
Voltage
120V
Sockets
Medium base porcelain with all copper current carrying components and spring loaded center contact
