• Super Ceiling Sensor has 3 detectors for triple overlapping coverage to catch small movements
  • LED testing and operation Indicator
  • Maximum coverage - 360 or hallway models
  • Relay and sensor all in one unit reduces installation costs
  • Can be wired in parallel
  • Compatible with program start ballasts
View Technical Specs
Dimensions
Link to Dimension Drawing

Weight: 0.6 lbs

Technical Specifications
Construction
Easy Installation
Relay and sensor all in one reduces installation cost. Compatible with program start ballasts. Not compatible with instant start ballasts. LED testing and operation indicator.
Sensor Settings
Maximum Reliability
Adjustable detector sensitivity for superior detection
Maximum Versatility
Adjustable time delay. Sensor detection pattern can be customized. No minimum load requirement. Can be wired in parallel.
Time Delay
10 seconds to 15 minutes
Adjustments
Photo Time Sensitivity
Detection
360° view Super Ceiling Sensor
Optical
Coverage Area
2152sf @ 9'
Electrical
Incandescent Watts Switched
2000W
Fluorescent Watts Switched
2000W
Ratings Amps Horsepower
16 amps 6.7 horsepower.
Power Consumption
Negligible
Manual Switch
None
Other
Warranty
RAB warrants that our LED products will be free from defects in materials and workmanship for a period of one (1) year from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.

Recently Viewed Products

 This is a link to the product LOS2500/120 LOS2500/120
Indoor Motion Sensors Los2500 120V
 This is a link to the product RBAY17L/LCBS/8CP2 RBAY17L/LCBS/8CP2
Linear High Bay400-320-260W 3500K/4000K/5000K 8' 7-15 Cp Lightcloud Blue Pir
 This is a link to the product H17XL/6CP2 H17XL/6CP2
H17 Highbay 240W/200W/150W 3000K/4000K/5000K 6' 7-15 Cp2 White
 This is a link to the product ARBAY4-360N/480/LC ARBAY4-360N/480/LC
Aerobay 4Ft 360W 4000K 480V Dim Lightcloud White
 This is a link to the product PRT55Y/LC PRT55Y/LC
