• Butterfly bracket allows mounting with bar stock, "C" channel, 1/2" conduit or nailer bars
  • Low-profile design allows for installation in ceilings with limited space
  • Absolute White 3-step consistency and black body accurate
  • Nanostructure lens eliminates "hot spots" providing smooth and efficient light
View Technical Specs
Performance
Watts 0W
Color Temp 3000K (Warm)
Lumens 12 lm
Efficacy lm/W
Color Accuracy 90 CRI
L70 Lifespan 100,000 hours
Type Sold Separately
120V
208V
240V
277V
Input Watts
Dimensions
Link to Dimension Drawing

Weight: 1.2 lbs

Technical Specifications
Compliance
UL Listed
Suitable for wet locations covered ceiling
ENERGY STAR V2.0
This product is ENERGY STAR® Version 2.0 Certified.
Construction
Trim Component
This component must be ordered with New Construction Round Rough-In in order to make a complete fixture. See here for New Construction Round Rough-In.
Housing
Professional-grade, die-cast aluminum construction
Trim Ring
Silver powder coated die cast trim ring
Trim Cone
Matte silver round trim cone
Drop Ceiling Installation
NDLED can be installed in drop ceiling tiles when using optional c-channel bars and following local construction codes
Aperture Size
4" Trim Module
Junction Box
Integral junction box with wiring capacity for
Min 90°C supply conductors
4 in 4 out
Easy Installation
The EZ-Connector makes installation easy
Electrical
Dimming Driver
0 - 10V (at 120-277V), TRIAC and ELV (at 120V only). See dimmer compatibility guide here.
Dimming
Dimmable. Requires rough-in with dimming driver.
Optical
Optics
50° beam spread with specular thermoplasic optics and Nanostructure lens technology for smooth light output and high efficiency
LED Characteristics
Color Consistency
3-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color
Other
Warranty
RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
Buy American Act Compliance
RAB values USA manufacturing! Upon request, RAB may be able to manufacture this product to be compliant with the Buy American Act (BAA). Please contact customer service to request a quote for the product to be made BAA compliant.
