P1M/480

Spec Sheet IES File LM79 Instructions Sell Sheet Folleto (Español) Family Spec Sheet Spec Sheet EZ Layout

P1M/480

100,000-Hour LED lifespan

IP65 rating protects against dust and water

10-Year, Limited warranty

View Technical Specs

View Price & Availability

Performance

Watts	600W
Color Temp	5700K
Lumens	84,769 lm
Efficacy	143.6
Color Accuracy	76 CRI
L70 Lifespan	100,000 Hours

Type	Constant Current
120V
208V	3.01A
240V	2.61A
277V	2.26A
Input Watts	590.5W

EZ-Layout

Create Custom Lighting Layout

Dimensions

Weight: 36.5 lbs

Technical Specifications

Compliance

UL Listed

Suitable for wet locations

IESNA LM-79 & LM-80 Testing

RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.

IP Rating

Ingress protection rating of IP65 for dust and water

Trade Agreements Act Compliant

This product is a product of Cambodia and a "designated country" end product that complies with the Trade Agreements Act

DLC Listed

This product is listed by Design Lights Consortium (DLC) as an ultra-efficient premium product that qualifies for the highest tier of rebates from DLC Member Utilities.
DLC Product Code: S-ZWXHP5

Electrical

Driver

Constant Current, Class 1, 200-480V, 50/60 Hz, 208V: 3.01A 240V: 2.61A, 277V: 2.26A, 480V: 1.31A

Dimming Driver

Driver includes wiring for 0-10V dimming systems. Dim as low as 10%.

THD

4.91% at 480V

Power Factor

97.3% at 480V

Surge Protection

20 kV

Aux Power Supply

Yes

Dim to Off

Yes

LED Characteristics

LEDs

Long-life, high-efficacy, surface-mount LEDs

Color Uniformity

RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.

Performance

Lifespan

100,000-Hour LED lifespan based on IESlm-80 results and TM-21 calculations

Wattage Equivalency

2000W Metal Halide

Construction

Cold Weather Starting

The minimum starting temperature is -40°F (-40°C)

Maximum Ambient Temperature

Suitable for use in up to 122°F (50°C)

Housing

Precision die-cast aluminum

Lens

Polycarbonate lens

Tilt Increment

Continuous tilting with 5° increments

Effective Projected Area (With Shield)

0°: 1.2864
15°: 1.2934
25°: 1.43
45°: 1.7071
60°: 1.873
75°: 2.0015
90°: 2.0669

Gaskets

High-temperature silicone

Finish

Formulated for high durability and long-lasting color

Green Technology

Mercury and UV free. RoHS-compliant components.

Installation

Mounting

Trunnion mount with stainless steel hardware

Optical

NEMA Type

NEMA Beam Spread 4H x 4V

Other

10-Year Limited Warranty

The RAB 10-year, limited warranty covers light output, driver performance and paint finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
