PAR20-7-940-25D-DIM
PAR20-7-940-25D-DIM
- Produces rich and vibrant colors >90CRI
- Energy efficient replacement for incandescent and halogen PAR lamps
- Constructed from durable materials which lowers risk of breakage
- Rated for use in enclosed and open fixtures in dry and damp locations*
- Single optic and full face lens for precise beam angle control
- Longer lifespan compared to legacy equivalents minimizes replacement and maintenance costs
- Title 20 Compliant, ENERGY STAR Compliant, UL Listed
- Dimmable down to 10% (check dimmer compatibility list)
- *PAR38 is wet rated
Performance
| Watts | 7W |
| Color Temp | 4000K (Cool White) |
| Lumens | 550 lm |
| Efficacy | 78.6 lm/W |
| Color Accuracy | 90 CRI |
| L70 Lifespan | 40,000 Hours |
| Input Voltage | 120V |
| Power Factor | 0.9 |
| Flicker | <30% |
| THDi | N/A |
| R9 | 50 |
Dimensions
Weight: 0.2 lbs
Technical Specifications
Performance
Product Type
PAR
Input Wattage
7W
Wattage Equivalency
50W Halogen
Lumens
550lm
Efficacy
79lm/W
L70 Lifespan
40,000 Hours
Construction
Bulb Shape
PAR20
For Use Outdoors in Open Fixtures
No
LED Characteristics
Color Temperature
4000K Cool White
Color Accuracy (CRI)
90 CRI
Beam Angle
25°
Installation
Base Type
E26 Edison
Electrical
Power Factor
0.9
Operating Temperature
-20°C to 45°C (-4°F to 113°F)
Dimmable
Yes, down to 10%
Input Voltage
120V
Flicker
<30%
Other
4-Year, No-Compromise Warranty
RAB warrants that our LED products will be free from defects in materials and workmanship for a period of four (4) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
Compliance
UL Listed
Yes
California Energy Commission (CEC) Status
Lawful for Sales in California
\
