PIP20Y/D10 USA
PIP20Y/D10 USA large main
  • 60,000-hour LED lifespan
  • Standard 0-10V dimming driver
  • 5-Year, limited warranty
 View Technical Specs
View Price & Availability
Performance
Watts 20W
Color Temp 3000K (Warm)
Lumens 2,692 lm
Efficacy 133.9 lm/W
Color Accuracy 72 CRI
L70 Lifespan 60,000 Hours
Type Constant Current
120V 0.16A
208V 0.10A
240V 0.09A
277V 0.08A
Input Watts 20.1W
Dimensions
Link to Dimension Drawing

Weight: 3.7 lbs

BAC icon
Technical Specifications
Compliance
UL Listed
Suitable for wet locations
IESNA LM-79 & LM-80 Testing
RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
Buy American Act Compliance
This product complies with the Buy American Act
Electrical
Driver
Constant Current, Class 2, 50/60 Hz, 2kV, 120 - 277VAC 120: 0.16A, 208V: 0.10A, 240V: 0.09A, 277V: 0.08A
Dimming Driver
Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%.
THD
12.8% at 120V, 14.1% at 277V
Power Factor
99% at 120V, 95.4% at 277V
LED Characteristics
LEDs
Long-life, high-efficacy, surface-mount LEDs
Performance
Lifespan
60,000-Hour LED lifespan based on IESlm-80 results and TM-21 calculations
Other
FTC Country of Origin
This product was assembled in the USA by RAB using imported components
