PLC-9-V-827-BYP
PLC-9-V-827-BYP large main
  • Replaces 18W/26W/32W G24d & G24q CFL Lamps
  • Ballast Bypass. Integral Driver enables lamp to be wired directly to line voltage without need for an external driver or ballast
  • Compatible with G24d / GX24d & G24q / GX24q installations
  • 50,000 hour Lifespan
  • Environmentally friendly, no mercury used
  • UL Classified
  • Rated for use in enclosed and open fixtures in dry or damp locations
  • Non-Dimmable
  • 5 Year No Compromise Warranty
 View Technical Specs
View Price & Availability
Performance
Watts 9W
Color Temp 2700K
Lumens 900 lm
Efficacy 100 lm/W
Color Accuracy 82 CRI
L70 Lifespan 50,000 Hours
Input Voltage 120-277V
Power Factor N/A
Flicker N/A
THDi N/A
Dimensions
Link to Dimension Drawing

Weight: 0.3 lbs

Technical Specifications
Performance
Product Type
Compact
Input Wattage
9W
Efficacy
100lm/W
L70 Lifespan
50,000 Hours
Construction
Shape
PLC
Finish
Frosted
For Use Outdoors in Open Fixtures
No
LED Characteristics
Color Temperature
2700K So ft White
Color Accuracy (CRI)
82 CRI
Installation
Base Type
G24d/G24q
Installation Type
Type B, Ballast Bypass
Installation Orientation
Vertical
Electrical
Operating Frequency
50/60Hz
Input Voltage
120-277V AC
Compliance
California Energy Commission (CEC) Status
Lawful for Sales in California
Application
Suitable for damp locations and totally enclosed fixtures.
