PLS-5.2-H-840-HYB

Spec Sheet IES File LM79 Instructions FCC Caution Spec Sheet EZ Layout

PLS-5.2-H-840-HYB

Replaces 13W CFL Lamps

Plug and Play on existing magnetic CFL ballasts or can be wired directly to line voltage without need for an external driver or ballast

Compatible with Gx23 base installations

50,000 hour Lifespan

Environmentally friendly, no mercury used

UL Classified

Rated for use in enclosed and open fixtures in dry or damp locations

5 Year No Compromise Warranty

View Technical Specs

View Price & Availability

Performance

Watts	5W
Color Temp	4000K
Lumens	600 lm
Efficacy	109
Color Accuracy	80 CRI
L70 Lifespan	50,000 Hours

Type	Constant Current
120V	0.05A
208V
240V
277V
Input Watts	5.5W

EZ-Layout

Create Custom Lighting Layout

Dimensions

Technical Specifications

Performance

Product Type

Compact

Input Wattage

5.5W

Lumens

600lm

Efficacy

109lm/W

L70 Lifespan

50,000-Hour LED lifespan based on IES LM-70 results

Wattage Equivalency

11W CFL

Compliance

UL Listed

Suitable for damp locations

Enclosed Fixtures

Suitable for use in enclosed fixtures

LED Characteristics

Color Temperature

4000K

Color Accuracy (CRI)

≥80 CRI

Beam Angle

120°

Construction

Shape

PLS-Horizontal

Endcap Material

Copper

Enclosure Material

Constructed from frosted, shatter-resistant polycarbonate

Installation

Base Type

Gx23

Electrical

THD

20%

Power Factor

0.9

Flicker

50%

Operating Temperature

-20°C to 45°C (-4°F to 113°F)

Input Voltage

120-277V

Operating Frequency

50/60Hz

Other

5-Year, No-Compromise Warranty

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
