• Replaces 13W CFL Lamps
  • Plug and Play on existing magnetic CFL ballasts or can be wired directly to line voltage without need for an external driver or ballast
  • Compatible with Gx23 base installations
  • 50,000 hour Lifespan
  • Environmentally friendly, no mercury used
  • UL Classified
  • Rated for use in enclosed and open fixtures in dry or damp locations
  • 5 Year No Compromise Warranty
View Technical Specs
Performance
Watts 5W
Color Temp 5000K
Lumens 600 lm
Efficacy 109.1
Color Accuracy 80 CRI
L70 Lifespan
Input Voltage 120-277V
Power Factor >0.9
Flicker 50%
THDi 20%
Dimensions
Link to Dimension Drawing
Technical Specifications
Performance
Product Type
Compact
Input Wattage
5.5W
Lumens
600lm
Efficacy
109.1lm/W
L70 Lifespan
50,000-Hour LED lifespan based on IES LM-70 results
Wattage Equivalency
11W CFL
LED Characteristics
Color Accuracy (CRI)
80 CRI
Beam Angle
120°
Color Temperature
5000K
Construction
Material
Polycarbonate
Bulb Shape
PLS-Horizontal
Installation
Base Type
Gx23
Electrical
Power Factor
>0.9
Input Voltage
120-277V
Operating Temperature
-20°C to 45°C (-4°F to 113°F)
Compliance
Enclosed Fixtures
Suitable for use in enclosed fixtures
UL Listed
Suitable for damp locations
UL Classified
Yes
Certification Model Number
T10369(PLS-5.2-H-850-HYB)
\
