PLT-17-V-830-DIR
PLT-17-V-830-DIR
- Replaces 42W G24q Lamps
- Ballast Compatible. Directly Compatible with Most Existing CFL Ballasts.
- Compatible with G24q / GX24q (4-pin CFL) installations
- 50,000 hour Lifespan
- Environmentally friendly, no mercury used
- UL Listed, DLC Listed
- Rated for use in enclosed and open fixtures in dry or damp locations
- 5 Year No Compromise Warranty
Performance
| Watts | 17W |
| Color Temp | 3000K |
| Lumens | 2,000 lm |
| Efficacy | 117.6 lm/W |
| Color Accuracy | 80 CRI |
| L70 Lifespan | 50,000 Hours |
| Type | Constant Current |
| 120V | Ballast Dependent |
| 208V | |
| 240V | |
| 277V | Ballast Dependent |
| Input Watts | 17W |
Dimensions
Weight: 0.7 lbs
Technical Specifications
Performance
Product Type
Compacts
Input Wattage
17W
Lumens
2,000lm
L70 Lifespan
50,000-Hour LED lifespan based on IES LM-70 results
Wattage Equivalency
42W G24q & Gx24q
Electrical
THD
<20%
Power Factor
>0.9
Dimmable
Not suggested for dimming applications
Input Voltage
120-277V AC
Operating Frequency
Ballast Dependent
Operating Temperature
Ballast Dependent
LED Characteristics
Color Accuracy (CRI)
80
Color Temperature
3000K
Construction
Bulb Shape
PLT-Vertical
Enclosure Material
Polycarbonate endcap with aluminum heatsink and glass envelop
Housing Finish
White
Lens Finish
Frosted
Base Type
4-Pin G24q
Installation
Installation Method
UL Type A, Plug and Play
Burning Position
Vertical
Other
Technology EQ
CFL
Warranty
RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
Buy American Act Compliance
RAB values USA manufacturing! Upon request, RAB may be able to manufacture this product to be compliant with the Buy American Act (BAA). Please contact customer service to request a quote for the product to be made BAA compliant.
Compliance
Listings
UL Listed
Environment
Damp / Enclosed
RoHS
Mercury and UV free. RoHS-compliant components.
FCC
Complies with Part 15B of the FCC Rules
Certification Model Number
T10217(PLT-17-V-830-DIR)
DLC Listed
This product is on the Design Lights Consortium (DLC) Qualified Products List and is eligible for rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.
DLC Product Code: PLFCDRGI7IQB
DLC Product Code: PLFCDRGI7IQB
