• High Performance LEDS up to 100 lm/w
  • Use to replace up to 100W traditional light sources
  • Durable metal construction: dent and scratch resistant
  • UL wet location rated
  • Compatible with most standard recessed housings
  • Dimmable down to 5% on compatible dimmers
  • Available in Round 4" 850lm and 6" 850lm, 1050lm and 1400lm
  • Available in 5 color temperatures: 2700K, 3000K, 3500K, 4000K, & 5000K
  • Available in a smooth and baffle trim option
  • Color designer trims as optional accessories available
  • 5-Year, No-Compromise Warranty
View Technical Specs
Performance
Watts 11W
Color Temp 3500K (Warm Neutral)
Lumens 1,004 lm
Efficacy 85.71428571
Color Accuracy 92 CRI
L70 Lifespan 50,000 Hours
Type Constant Current
120V 0.09A
208V
240V
277V
Input Watts 10W
Dimensions
Link to Dimension Drawing

Weight: 0.8 lbs

Technical Specifications
Compliance
UL Classified
Suitable for wet locations
Energy Star Approved
ENERGY STAR® Version 2.2 Certified
Certification Model Number
DLR0027
Energy Star ID
2350031
NEC Compliant
Suitable for use in closets. Compliant with NEC Sec. 410.16 (A)(1) and 410.16 (C5).
California Title 24
Can be used to conform with the requirements of California Title 24 Part 6.
California Title 20 Compliant
Compliant LED Product
Electrical
Dimming Driver
TRIAC compatible dimmer with dimming as low as 5%. See dimmer compatibility guide here.
THD
<20%
Power Factor
≥0.9
THDi
Produces less than 20% THD
PF
≥0.9
Input Voltage
120V
Operating Frequency (Hz)
60Hz
Performance
Lifespan
50,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations
Wattage Equivalency
75W Incandescent
Construction
Shape
Round
Trim Style
Baffle
Housing
Constructed from durable steel sheet metal
Cold Weather Starting
The minimum starting temperature is -30°C (-22°F)
Maximum Ambient Temperature
Suitable for use in up to 40°C (104°F)
Lens
Frosted polycarbonate diffusion lens. Regressed lens. Constructed from durable sheet metal construction.
Green Technology
Mercury and UV free. RoHS-compliant components.
Socket Adapter
Edison 26 Medium Base Socket adapter included in box
Finish
Matte White
LED Characteristics
Beam Angle
95°±10°
LEDs
Long-life, high-efficacy, surface-mount LEDs
R9 Value
High color performance with R9 greater than or equal to 50
Flicker
Silent and flicker free operations of less than 30%
Installation
Mounting
Easy installation with friction clips (4") and torsion springs (5"/6")
Other
Compatibility
Compatible with most 5" and 6" recessed housings
5-Year, No-Compromise Warranty
RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
