• IP65 rated
  • 100,000-Hour LED lifespan
  • 5-Year Limited Warranty
View Technical Specs
Performance
Watts 8W
Color Temp Tunable White 2200-4000K
Lumens 3-221 lm
Efficacy 1.3-26.9 lm/W
Color Accuracy 63-93 CRI
L70 Lifespan 100,000 Hours
Type Constant Current
120V 0.07A
208V 0.04A
240V 0.04A
277V 0.04A
Input Watts 2.37-8.23W
Dimensions
Link to Dimension Drawing

Weight: 4.6 lbs

Technical Specifications
Compliance
UL Listed
Suitable for wet locations
IP Rating
Ingress protection rating of IP65 for dust and water
IESNA LM-79 & LM-80 Testing
RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
LED Characteristics
LEDs
Long-life, high-efficacy, discrete, surface-mount LEDs
Color Tuning
Yes, 2200K-4000K and 16+ million colors to choose from using the Lightcloud Blue mobile app.
Default Setting at 3000K.
Color Consistency
7-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color
Color Uniformity
RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for (SSL) Products, ANSI C78.377-2017.
Electrical
Driver
Constant Current, Class 2, 120-277V, 50/60 Hz, 120V: 0.07A, 208V: 0.04A, 240V: 0.04A, 277V: 0.04A
THD
11.7% at 120V, 12.8% at 277V
Power Factor
97.3% at 120V, 70.5% at 277V
Dim to Off
No
Aux Power Supply
No
Construction
Cold Weather Starting
The minimum starting temperature is -40°F (-40°C)
Maximum Ambient Temperature
Suitable for use in up to 113°F (45°C)
Housing
Die-cast aluminum
Lens
Glass
Gaskets
High-temperature silicone
Green Technology
Mercury and UV free. RoHS-compliant components.
Installation
Mounting
3pcs anchor bolts for mounting
Other
5-Year Limited Warranty
The RAB 5-year, limited warranty covers light output, driver performance and paint finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
