SEAL2/LCBS/MVS/E
SEAL2/LCBS/MVS/E
25W 3500K/4000K/5000K
- 100,000-Hour LED lifespan
- DLC Premium Listed
- 0-10V dimming, standard
- 5-Year, limited warranty
Performance
| Watts | 25W |
| Color Temp | 3500K/4000K/5000K |
| Lumens | 2040-3400 lm |
| Efficacy | 130-142 lm/W |
| Color Accuracy | 80 CRI |
| L70 Lifespan | 100,000 Hours |
| Type | Constant Current |
| 120V | 0.23A |
| 208V | 0.13A |
| 240V | 0.12A |
| 277V | 0.10A |
| Input Watts | 25/20/15W |
Dimensions
Weight: 4.0 lbs
Technical Specifications
Compliance
UL Listed
Suitable for wet locations
UL 94
5VA flame classification
FCC
Complies with Part 15B of the FCC Rules
NSF
NSF Certified by Public Health and Safety
NEMA Rating
4X, protected against corrosion
IESNA LM-79 & LM-80 Testing
RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
IP Rating
Ingress protection rating of IP65 for dust and water
DLC Listed
This product is listed by Design Lights Consortium (DLC) as an ultra-efficient premium product that qualifies for the highest tier of rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.
DLC Product Code: S-2WR1TU
DLC Product Code: S-2WR1TU
Electrical
Driver
Constant Current, Class 2, 120-277V, 50/60Hz, 120V: 0.23A, 208V:0.13A, 240V: 0.12A, 277V 0.10A
Dimming Driver
Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%.
THD
3.55% at 120V, 4.59% at 277V
Power Factor
99.9% at 120V, 97.74% at 277V
Surge Protection
2.5kV
Battery Backup
Battery backup will operate the fixture for 90 minutes if power fails. Wired for 120-277V.
Battery Backup Light Loss Factor
0.232
LED Characteristics
LEDs
Long-life, high-efficacy, surface-mount LEDs
Color Uniformity
RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.
Performance
Lifespan
100,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations
Wattage Equivalency
Equivalent to (2) F32T8 or (3) F17T8
Construction
Housing
Impact-resistant polycarbonate* with stainless steel door clips. 1/2" NPS opening for conduit and bushing/cord entry. *Polycarbonate is affected by cleaning agents or other liquids containing partial solvents such as low molecular weight aldehydes and ethers, ketones, esters, aromatic hydrocarbons and perchlorinated hydrocarbons. Click here for a detailed list of damaging chemicals.
Mounting
Quick-mount, stainless steel snap on brackets supplied for surface mounting. V-Hook brackets supplied standard for suspending the fixture.
Lens
Diffuse polycarbonate lens for low glare and maximum protection
Reflector
Cold-rolled steel
Gaskets
High-temperature silicone gaskets
Cold Weather Starting
The minimum starting temperature is -40°C (-40°F)
Maximum Ambient Temperature
Suitable for use in up to 40°C (104°F)
Installation
Tether Cables are provided for easy installation. Quick connector may be used for quick and easy wiring.
Green Technology
Mercury and UV free. RoHS-compliant components.
Finish
Formulated for high durability and long-lasting color
Lightcloud
Lightcloud Blue Sensor Installed
Occupancy, vacancy, and closed loop daylight harvesting in one versatile sensor. In addition control any fixture in your Lightcloud Blue integrated/embedded networked lighting luminaire-level control system. LLLC - capable of switching, 0-10V dimming, power/energy monitoring. Can also be used to extend the range of the Lightcloud Blue utilizing a "BLE Mesh" network communication protocols. The Lightcloud Blue sensor can be attached to the fixture provided an unobstructed view of the coverage area is available.
DLC system - N1XMLOEATBA
Learn more about Lightcloud.
DLC system - N1XMLOEATBA
Learn more about Lightcloud.
Sensor Specifications
Maxmium Mounting Height
19.68ft. (6m)
Operating Voltage
DC Input: 10.5-15V
Dimming Control
ON/OFF 0-10V Dimmable
Operating Temperature
-20°C to 70°C (-4°F to 158°F)
IP Rating
Ingress protection rating of IP65 for dust and water
Brightness
Factory Setting: 100%
Sensitivity Setting
25%/50%/75%/100%
(Factory Setting: 50%)
(Factory Setting: 50%)
Standby Period
0s/10s/30s/1min/5min/10min/30min/60min/+∞
(Factory Setting: 1min)
(Factory Setting: 1min)
Daylight
2Lux/10Lux/30Lux/50lLux/80Lux/120Lux/Disabled
(Factory Setting: disabled)
(Factory Setting: disabled)
Hold Time
5s/30s/1min/3min/5min/10min/20min/30min
(Factory Setting: 20min)
(Factory Setting: 20min)
Standby Dimming
10%20%/30%/50%
(Factory Setting: 20%)
(Factory Setting: 20%)
Detection Angle
30° to 150° without glass cover
Detection Distance
Radius 9.95-22.96ft (3-7m)
Remote Control Accessory
Adjust settings using remote control (catalog# MSR1). Only available with 0-10V dimming driver options. Remote control available here.
Other
5 Yr Limited Warranty
The RAB 5-year, limited warranty covers light output, driver performance and paint finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
Buy American Act Compliance
RAB values USA manufacturing! Upon request, RAB may be able to manufacture this product to be compliant with the Buy American Act (BAA). Please contact customer service to request a quote for the product to be made BAA compliant.
