SHARK2/PIR/E

25W 3500K/4000K/5000K

Impact-resistant linear washdown

Ideal for tunnels and stairwells

Mounting options: Chain, junction box, angled surface mount or vandal-resistant surface mount

IP66 Rating protects against dust & water ingress

5-Year, No-Compromise Warranty

100,000-Hour LED lifespan

View Technical Specs

View Price & Availability

Performance

Watts	25/20/15W
Color Temp	3500K/4000K/5000K
Lumens	2,270-3,683 lm
Efficacy	137.6-148.2 lm/W
Color Accuracy	83-85 CRI
L70 Lifespan	100,000 Hours

Type	Constant Current
120V	0.21A/0.17A/0.13A
208V	0.12A/0.10A/0.09A
240V	0.11A/0.09A/0.08A
277V	0.10A/0.08A/0.07A
Input Watts	16-25.7W

EZ-Layout

Create Custom Lighting Layout

Dimensions

Technical Specifications

Compliance

UL Listed

Suitable for wet locations

NSF

NSF Certified by Public Health and Safety

NEMA Rating

4X, protected against corrosion

DLC Listed

This product is on the Design Lights Consortium (DLC) Qualified Products List and is eligible for rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.
DLC Product Code: S-V3CE02 (Direct Linear Ambient Luminaires)
DLC Product Code: S-W04BEC (Stairwell and Passageway Luminaires)

Electrical

Dimming Driver

Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%.

THD

2.15% at 120V, 3.37% 277V

Power Factor

99.8% at 120V, 95.6% at 277V

Surge Protection

2.5kV

Battery Backup

Battery backup will operate the fixture for 90 minutes if power fails. Wired for 120-277V.

Battery Backup Light Loss Factor

0.232

Construction

Housing

IK09 impact-resistant polycarbonate with 5VA flame rating*
1/2" openings for conduit and bushing/cord entry
*Polycarbonate is affected by cleaning agents or other liquids containing partial solvents such as low molecular weight aldehydes and ethers, ketones, esters, aromatic hydrocarbons and perchlorinated hydrocarbons. Click here for a detailed list of damaging chemicals.

Mounting

Quick-mount, surface, stainless steel spring clips supplied. 4 additional mounting accessory kits available.

Lens

Diffuse polycarbonate lens for low glare and maximum protection

Maximum Ambient Temperature

Suitable for use in up to 40°C (104°F)

Cold Weather Starting

The minimum starting temperature is -40°C (-40°F)

Green Technology

Mercury and UV free. RoHS-compliant components.

Finish

Formulated for high durability and long-lasting color

LED Characteristics

LEDs

Long-life, high-efficacy, surface-mount LEDs

Color Stability

LED color temperature is warrantied to shift no more than 200K in color temperature over a 5-year period

Color Uniformity

RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.

Performance

Lifespan

100,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations

Sensor Specifications

Passive Infrared Occupancy and Daylight Sensor

PIR sensor with IR remote capability. High/Low bay passive infrared occupancy and daylight sensor.

UL Listed

Indoor use only

Brightness

Factory Setting: 100%

Hold Time

1 minute

Daylight

Disabled

Sensitivity

100%

Stand-By Dimming Level

20%

Stand-By Time

1 minute

Operating Voltage

12 ± 2V DC

Operating Current

30mA

Output

DIM 0-10V

Stand-By Power

<0.5W

Daylight Threshold

10Lux/30Lux/50Lux/100Lux/Disable

Lux On-Off

Adopted dual PD technology

Detection Angle

≤120° (wall mounted) 360° (ceiling mounted)

Control Line

Black White 12V+ ; Purple: DIM+ ; Pink GND/DIMMounting

Height

Max 20ft/6M (ceiling mounted)

Detection Range

Max 26ft/8M (ceiling mounted) Max 20ft/6m (wall mounted)

Operating Temperature

-30°C to +60°C (-22°F to + 140°F)

Other

Warranty

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.

Buy American Act Compliance

RAB values USA manufacturing! Upon request, RAB may be able to manufacture this product to be compliant with the Buy American Act (BAA). Please contact customer service to request a quote for the product to be made BAA compliant.
