SLIM17FAFC100/MVS
SLIM17FAFC100/MVS
- Selectable CCT
- Full cutoff
- Selectable on/off photocell
- 0-10V dimming, standard
Performance
| Watts | 100W |
| Color Temp | 3000/4000/5000K |
| Lumens | 13,780/15,088/14,505 lm |
| Efficacy | 135.25/153.33/142.89 lm/W |
| Color Accuracy | 84/86/83 CRI |
| L70 Lifespan | 100,000 Hours |
| Type | Constant Current |
| 120V | 0.85A |
| 208V | 0.49A |
| 240V | 0.42A |
| 277V | 0.38A |
| Input Watts | 101.89/98.4/101.5W |
Dimensions
Weight: 10.6 lbs
Technical Specifications
Field Adjustability
Field Adjustable
Color temperature selectable by 3000K, 4000K and 5000K (factory default 4000K)
Compliance
UL Listed
Suitable for Wet Locations. Wall Mount Only.
IESNA LM-79 & LM-80 Testing
RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
IP Rating
Ingress protection rating of IP65 for dust and water
DLC Listed
This product is listed by Design Lights Consortium (DLC) as an ultra-efficient premium product that qualifies for the highest tier of rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.
DLC Product Code: S-G9SLFV
DLC Product Code: S-G9SLFV
Performance
Lifespan
100,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations
Wattage Equivalency
Equivalent to 400W Metal Halide
LED Characteristics
LEDs
Long-life, high-efficiency, surface-mount LEDs
Electrical
Driver
Constant Current, Class 1, 120-277V, 50/60 Hz, 120V: 0.85A, 208V: 0.49A, 240V: 0.42A, 277V: 0.38A
Dimming Driver
Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%.
THD
9.53% at 120V, 6.12% at 277V
Power Factor
99.5% at 120V,, 95.6% at 277V
Photocell
120-277V selectable photocell that can be turned on and off.
Surge Protection
L/N-PE: 6KV L-N; 6KV
Dim to Off
Yes
Aux Power Supply
Yes
Construction
IK Rating
IK08 Protected against 5 joules of impact. Equivalent to the impact of a 3.75 lbs. (1.7kg) mass dropped from 11.8" (300mm) above the impacted surface.
Cold Weather Starting
The minimum starting temperature is -40°C (-40°F)
Ambient Temperature
Max Power Temp Rating: 50°C (122°F)
Middle Power Temp Rating: 50°C (122°F))
Low Power Temp Rating: 50°C (122°F)
Middle Power Temp Rating: 50°C (122°F))
Low Power Temp Rating: 50°C (122°F)
Housing
Precision die-cast aluminum housing and door frame
Lens
Polycarbonate lens
Cut Off
Full cutoff (0°)
Gaskets
High-temperature silicone
Finish
Formulated for high durability and long-lasting color
Green Technology
Mercury and UV free. RoHS-compliant components.
Installation
Mounting
Hinged wiring access and conduit entries on the back, sides, top and bottom make installation a snap
Other
5-Year Limited Warranty
The RAB 5-year, limited warranty covers light output, driver performance and paint finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
Sensor Settings
Factory Settings
Brightness: 100%
Hold Time: 1 Minute
Daylight: Disabled
Sensitivity: 50%
Stand-by dimming level: 20%
Stand-by time: 1 Minute
Hold Time: 1 Minute
Daylight: Disabled
Sensitivity: 50%
Stand-by dimming level: 20%
Stand-by time: 1 Minute
Capacitance Load
400VA at 120VAC, 800VA at 230VAC, 1000VA at 277VAC
Operating Temperature
-20°C to +60°C (-4°F to +140°F)
Relay
Zero-cross relay
Maximum Mounting Height
49.2 ft (15M)
Customizable Detection Area
10, 50, 75 or 100%
Time Delay
5s, 30s, 1min, 5min, 10min, 20min, 30min
Cut Off Period
0s, 10s, 1min, 5min, 10min, 30min, 1hr, Bi-Level
Cut-Off Dimming level
10, 20, 30, 50%
Cut-Off Power
Less than 1W
Daylight Threshold
About .2-5 fc for disabled
Sensor Principle
High Frequency
Microwave Frequency
5.8GHz +/- 75MHz
Microwave Power
<0.2mW
Max Detection Range
26 ft diameter at 16 ft mounting height
Detection Angle
About 30 to 150 degrees
Remote Control
Adjust settings using remote control (catalog# MSR1). Only available with 0-10V dimming driver options. Remote control available here.
