T34-2X2-20/D10
T34-2X2-20/D10
- Integrated 0-10V dimming
- 50,000-Hour LED lifespan
- 5-Year, limited warranty
- 4 per case, must order in case quantity increments
Performance
| Watts | 20W |
| Color Temp | 5000K (Cool) |
| Lumens | 2,856 lm |
| Efficacy | 133 |
| Color Accuracy | 81 CRI |
| L70 Lifespan | 50,000 Hours |
| Type | Constant Current |
| 120V | 0.17A |
| 208V | 0.10A |
| 240V | 0.09A |
| 277V | 0.08A |
| Input Watts | 21.6W |
Dimensions
Weight: 5.2 lbs
Technical Specifications
Compliance
UL Listed
Suitable for damp locations
CCEA Compliant
Luminaire Requirements used in Environmental Air Space per the electrical code specification of the City of Chicago
IESNA LM-79 & LM-80 Testing
RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
Trade Agreements Act Compliant
This product is a product of Cambodia and a "designated country" end product that complies with the Trade Agreements Act
DLC Listed
This product is on the Design Lights Consortium (DLC) Qualified Products List and is eligible for rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.
DLC Product Code: S-B83LH4
DLC Product Code: S-B83LH4
Construction
IC Rated
Suitable for direct contact with insulation
Operating Temperature
-20°C (-4°F) to 40°C (104°F)
Lens
Frosted polystyrene
Housing
Plastic frame & galvanized steel back housing
Finish
White
Green Technology
Mercury and UV free. RoHS-compliant components.
LED Characteristics
LEDs
Long-life, high-efficiency, surface-mount LEDs
Performance
Lifespan
50,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations
Electrical
Driver
Constant Current, Class 2, 120-277V, 50/60 Hz, 2kV surge protection, 120V: 0.17A, 208V: 0.10A, 240V: 0.09A, 277V: 0.08A
THD
8.58% at 120V, 14.65% at 277V
Power Factor
98.5% at 120V, 88.7% at 277V
Dimming
0-10V, standard down to 10%
Installation
Mounting
Recessed into T-grid ceiling. Surface and recessed mounting kits available for drywall ceilings.
Other
5 Yr Limited Warranty
The RAB 5-year, limited warranty covers light output, driver performance and paint finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
