Integrated/embedded networked lighting control, luminaire-level lighting control. Fixture, Zone, and plug-load control from one powerful device. LLLC - capable of switching, 0-10Vdimming, power/energy monitoring. Can also be used to extend the range of the Lightcloud mesh network communication protocols. Offers the capability to set the maximum light output to a less-than-maximum state of an individual luminaire at the time of installation or commissioning. The High-End trim functionality is field reconfigurable via the Lightcloud mesh network communication protocols. The Lightcloud controller can be attached to the fixture, junction box, or electrical panel.
DLC system - N1XMLOEATBA
Learn more at www.lightcloud.com

Suitable for damp locations

Suitable for direct contact with insulation

Luminaire Requirements used in Environmental Air Space per the electrical code specification of the City of Chicago

RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.

This product is a product of Cambodia and a "designated country" end product that complies with the Trade Agreements Act

This product family is listed with the DesignLights Consortium (DLC). Individual SKUs within this family may carry either a DLC Standard or DLC Premium qualification. Please refer to the individual product specification sheet or the DLC Qualified Products List (QPL) at designlights.org to confirm the qualification status of a specific SKU prior to specification or purchase.

Long-life, high-efficiency, surface-mount LEDs

50,000-Hour LED lifespan based on IESlm-80 results and TM-21 calculations

Constant Current, Class 2, 120-277V, 50/60 Hz, 2kV surge protection, 120V: 0.34A, 208V: 0.20A, 240V: 0.17A, 277V: 0.15A

9.26% at 120V, 12.24% at 277V

99.1% at 120V, 96.1% at 277V

0-10V, standard down to 10%

-4°F(-20°C) to 104°F (40°C )

Frosted polystyrene

Plastic frame & galvanized steel back housing

White

Mercury and UV free. RoHS-compliant components.

Recessed into T-grid ceiling. Surface and recessed mounting kits available for drywall ceilings.

The RAB 5-year, limited warranty covers light output, driver performance and paint finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
