VXBRLED13

Spec Sheet IES File LM79 Instructions Spec Sheet EZ Layout

VXBRLED13

High performance LED light engine

100,000-hour life based on LM-80 results and TM-21 calculations

Die Cast Aluminum Housing

Classic design with state of the art LED technology

View Technical Specs

View Price & Availability

Performance

Watts	13W
Color Temp	5000K (Cool)
Lumens	507 lm
Efficacy	33.1 lm/W
Color Accuracy	86 CRI
L70 Lifespan	100,000 Hours

Type	Constant Current
120V	0.3A
208V	0.3A
240V	0.3A
277V	0.15A
Input Watts	15.3W

EZ-Layout

Create Custom Lighting Layout

Dimensions

Weight: 5.8 lbs

Technical Specifications

Performance

Lifespan

100,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations

Construction

Specification

These specifications are for fixture with Frosted Glass Globe and Die Cast Guard combination. Consult warehouse for different fixture combinations.

Globes and Guards

Vaporproof LEDs are compatible with RAB Globes and Guards

Construction

Die cast aluminum housing and door. Tether connects back housing halves for safety.

Cold Weather Starting

The minimum starting temperature is -40°F (-40°C)

Ambient Temperature

Suitable for use in up to95°F(35°C)

Housing

Die-cast aluminum housing and driver housing

Reflector

High quality hydroformed semi-specular aluminum

Gaskets

High-temperature Silicone

Finish

Natural shot blasted aluminum

Green Technology

Mercury and UV free. RoHS-compliant components.

Compliance

UL Listed

Suitable for Wet locations only with outer globe and as a Downlight

IESNA LM-79 & LM-80 Testing

RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.

Trade Agreements Act Compliant

This product is a product of Cambodia and a "designated country" end product that complies with the Trade Agreements Act

LED Characteristics

Color Temperature

3000K

Color Consistency

3-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color

Color Stability

LED color temperature is warrantied to shift no more than 200K in color temperature over a 5-year period

Color Uniformity

RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.

Electrical

Driver

Multi-chip single 13W high output long life LED Driver. Constant Current,100V-277V, 50/60 Hz., 100-240VAC.3-.15 Amps 277VAC.15 Amps. Will deliver 70% of its initial lumens at 100,000 hours based onlm-80 Tests.

Surge Protection

4 kV

Installation

Mounting

Three 1/2" NPS conduit entry points

Other

5-Year, No-Compromise Warranty

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.

Patents

The VXBRLED design is protected by Taiwan Patent 01510951 and patents pending in the U.S., Canada, China, and Mexico.

Optical

BUG Rating

B0 U2 G1
