VXBRLED13YDG

Vaporproof LED Wall Mount

Superior Thermal Management (Patent Pending)

All Die-Cast Aluminum Construction

100,000-hour life based on LM-80 results and TM-21 calculations

Thermal Shock-Resistant Frosted Glass Globe

Traditional Look, Cutting-Edge Technology

5-Year, No-Compromise Warranty

View Technical Specs

View Price & Availability

Performance

Watts	13W
Color Temp	3000K (Warm)
Lumens	507 lm
Efficacy	33.1 lm/W
Color Accuracy	86 CRI
L70 Lifespan	100,000 Hours

Type	Constant Current
120V	0.13A
208V	0.08A
240V	0.07A
277V	0.06A
Input Watts	15.3W

EZ-Layout

Create Custom Lighting Layout

Dimensions

Weight: 5.8 lbs

Technical Specifications

Performance

Lifespan

100,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations

Wattage Equivalency

Equivalent to 26W CFL

Construction

Globes and Guards

Vaporproof LEDs are compatible with RAB Globes and Guards

Construction

Die cast aluminum housing and door. Tether connects back housing halves for safety.

Cold Weather Starting

The minimum starting temperature is -40°C (-40°F)

Ambient Temperature

Suitable for use in up to 35°C (95°F)

Housing

Die-cast aluminum housing and driver housing

Guard and Globe

Shot blasted guard with frosted globe

Reflector

High quality hydroformed semi-specular aluminum

Gaskets

High-temperature Silicone

Finish

Natural shot blasted aluminum

Green Technology

Mercury and UV free. RoHS-compliant components.

Electrical

Driver

Multi-chip single 13W high output long life LED Driver. Constant Current,100V-277V, 50/60 Hz., 100-240VAC.3-.15 Amps 277VAC.15 Amps. Will deliver 70% of its initial lumens at 100,000 hours based onlm-80 Tests.

Surge Protection

4kV

Installation

Mounting

Three 1/2" NPS conduit entry points

Compliance

IESNA LM-79 & LM-80 Testing

RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.

UL Listed

UL Listed Suitable for Wet locations as a Downlight

Trade Agreements Act Compliant

This product is a product of Cambodia and a "designated country" end product that complies with the Trade Agreements Act

LED Characteristics

Color Consistency

3-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color

Color Stability

LED color temperature is warrantied to shift no more than 200K in color temperature over a 5-year period

Color Uniformity

RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.

Other

5-Year, No-Compromise Warranty

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.

Optical

BUG Rating

B0 U2 G1
