A34-3T125/WS2
Performance
| Watts | 125W |
| Color Temp | 5000K (Cool) |
| Lumens | 16,116 lm |
| Efficacy | 138.3 |
| Color Accuracy | 84 CRI |
| L70 Lifespan | 50,000 Hours |
| Type | Constant Current |
| 120V | 1.04A |
| 208V | 0.60A |
| 240V | 0.52A |
| 277V | 0.45A |
| Input Watts | 116.5W |
Dimensions
Weight: 16.2 lbs
Technical Specifications
Compliance
UL Listed
Suitable for wet locations
T24 JA8 Compliant
Can be used to conform with the requirements of California Title 24 Part 6.
IESNA LM-79 & LM-80 Testing
RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
DLC Listed
This product family is listed with the DesignLights Consortium (DLC). Individual SKUs within this family may carry either a DLC Standard or DLC Premium qualification. Please refer to the individual product specification sheet or the DLC Qualified Products List (QPL) at designlights.org to confirm the qualification status of a specific SKU prior to specification or purchase.
Electrical
Driver
Constant Current, Class 1, 120-277V, 50/60Hz, 120V: 1.04A, 208V: 0.60A, 240V: 0.52A, 277V: 0.45A
Dimming Driver
Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 5%.
THD
3.34% at 120V, 4.82% at 277V
Power Factor
99.7% at 120V, 97.7% at 277V
Performance
Lifespan
50,000-Hour LED lifespan based on IESlm-80 results and TM-21 calculations
