A34-5T55SF
Performance
| Watts | 55W |
| Color Temp | 5000K (Cool) |
| Lumens | 8,447 lm |
| Efficacy | 142.5 |
| Color Accuracy | 84 CRI |
| L70 Lifespan | 50,000 Hours |
| Type | Constant Current |
| 120V | 0.50A |
| 208V | 0.27A |
| 240V | 0.23A |
| 277V | 0.20A |
| Input Watts | 59.3W |
Dimensions
Weight: 12.6 lbs
Technical Specifications
Compliance
UL Listed
Suitable for wet locations
T24 JA8 Compliant
Can be used to conform with the requirements of California Title 24 Part 6.
IESNA LM-79 & LM-80 Testing
RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
DLC Listed
This product family is listed with the DesignLights Consortium (DLC). Individual SKUs within this family may carry either a DLC Standard or DLC Premium qualification. Please refer to the individual product specification sheet or the DLC Qualified Products List (QPL) at designlights.org to confirm the qualification status of a specific SKU prior to specification or purchase.
Electrical
Driver
Constant Current, Class 2, 120-277V, 50/60Hz, 120V: 0.50A, 208V: 0.27A, 240V: 0.23A, 277V: 0.20A
Dimming Driver
Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 5%.
THD
6.01% at 120V, 6.13% at 277V
Power Factor
99.5% at 120V, 95.7% at 277V
Performance
Lifespan
50,000-Hour LED lifespan based on IESlm-80 results and TM-21 calculations
