A34T5XLSF/480/MVS
A34T5XLSF/480/MVS
340W 3000/4000/5000K
- 100,000-hour LED Life
- 0-10V dimming standard
- IP65 rating protects against dust and water
- 5-Year, limited warranty
Performance
| Watts | 340/270/220W |
| Color Temp | 3000/4000/5000K |
| Lumens | 36,797-55,086 lm |
| Efficacy | 155.4-181.4 lm/W |
| Color Accuracy | 81-84 CRI |
| L70 Lifespan | 100,000 Hours |
| Type | Constant Current |
| 120V | |
| 208V | |
| 240V | |
| 277V | |
| Input Watts | 214-329.3W |
Dimensions
Technical Specifications
Field Adjustability
Field Adjustable
Field Adjustable Light Output:
340W/270W/220W (factory default 270W)
Color temperature selectable by 3000K, 4000K and 5000K (factory default 4000K)
340W/270W/220W (factory default 270W)
Color temperature selectable by 3000K, 4000K and 5000K (factory default 4000K)
Compliance
UL Listed
Suitable for wet locations
IESNA LM-79 & LM-80 Testing
RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
IP Rating
Ingress protection rating of IP65 for dust and water
DLC Listed
This product is listed by Design Lights Consortium (DLC) as an ultra-efficient premium product that qualifies for the highest tier of rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.
DLC Product Code: S-G6S0VV
DLC Product Code: S-G6S0VV
Performance
Lifespan
100,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations
Wattage Equivalency
340W: Replaces up to 1,000W Metal Halide (MH) or 1,000W High Pressure Sodium (HPS)
270W: Replaces up to 1,000W Metal Halide (MH) or 750W High Pressure Sodium (HPS)
220W: Replaces up to 750W Metal Halide (MH) or 600W High Pressure Sodium (HPS)
270W: Replaces up to 1,000W Metal Halide (MH) or 750W High Pressure Sodium (HPS)
220W: Replaces up to 750W Metal Halide (MH) or 600W High Pressure Sodium (HPS)
Electrical
Driver
340W: Constant Current, Class 1, Class P, 480V, 50/60 Hz,120V: 480V: 0.70A
270W: Constant Current, Class 1, Class P, 480V, 50/60 Hz,120V: 480V:0.59A
220W: Constant Current, Class 1, Class P, 480V, 50/60 Hz,120V: 480V:0.49A
270W: Constant Current, Class 1, Class P, 480V, 50/60 Hz,120V: 480V:0.59A
220W: Constant Current, Class 1, Class P, 480V, 50/60 Hz,120V: 480V:0.49A
Dimming Driver
Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%.
Surge Protection
L-L: 6 kV; L/N-G: 10 kV
10 kV Surge suppressor in addition to surge built into the driver.
10 kV Surge suppressor in addition to surge built into the driver.
Photocell
Integrated photocell included with on/off switch
Construction
IES Classification
The Type V distribution produces light in a wide and uniform 360° pattern that is perfect for large outdoor areas such as parking lots, corporate parks and retail settings
Cold Weather Starting
The minimum starting temperature is -40°F (-40°C)
Maximum Ambient Temperature
Suitable for use in up to 104°F (40°C)
Lens
Clear polycarbonate lens
Housing
Die-cast aluminum housing, lens frame and mounting arm
Effective Projected Area
EPA = 0.6
Tilt Increment
The fixture can be rotated from 0-125° in 5° increments
Vibration Rating
2G
Finish
Formulated for high durability and long-lasting color
Green Technology
Includes recycled plastic and RoHS-compliant components.
LED Characteristics
LEDs
Long-life, high-efficiency, surface-mount LEDs
Color Uniformity
RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.
Installation
Mounting
Slipfitter for 2 3/8"OD pipe
Optical
BUG Rating
340W: B5 U0 G4
270W: B5 U0 G4
220W: B5 U0 G4
270W: B5 U0 G4
220W: B5 U0 G4
Sensor Settings
Operating Voltage
DC Input: 10.5-15V
Current>50mA
Current>50mA
Operating Temperature
Ta: -31° F (-35° C)* ~ +122° F(+50° C)
Sensor Warranty
5-year sensor warranty
Sensitivity
100%
Standby Period
0s/10s/30s/1min/5min/10min/30min/60min/+∞
Daylight
2Lux/10Lux/30Lux/50Lux/80Lux/120Lux/Disable
Hold Time
20 minutes
Standby Dimming
10%/20%/30%/50%
Detection Angle
30° to 150° without glass cover
Detection Distance
Radius 9.84-22.96ft(3-7m)
Mounting Height
Max 49ft.(15m)
Remote Control Accessory
Adjust settings using remote control (catalog# MSR1). Only available with 0-10V dimming driver options. Remote control available here.
Other
5-Year Limited Warranty
The RAB 5-year, limited warranty covers light output, driver performance and paint finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
