ARBAY2-145N/LCS/8CPT2
ARBAY2-145N/LCS/8CPT2 large main
  • High efficiency. Low price.
  • Ideal for industrial warehouse spaces
  • 100,000 hour LED lifespan
  • 5-Year, limited warranty
 View Technical Specs
View Price & Availability
Performance
Watts 145W
Color Temp 4000K (Neutral)
Lumens 20,642 lm
Efficacy 142.6
Color Accuracy 84 CRI
L70 Lifespan 100,000 Hours
Type Constant Current
120V 1.22A
208V
240V
277V
Input Watts 144.8W
Dimensions
Link to Dimension Drawing

Weight: 13.9 lbs

Technical Specifications
Compliance
UL Listed
Suitable for damp locations
IESNA LM-79 & LM-80 Testing
RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
DLC Listed
This product is listed by Design Lights Consortium (DLC) as an ultra-efficient premium product that qualifies for the highest tier of rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.
DLC Product Code: PFBXC1BG
Construction
Operating Temperature
-4°F(-20°C) to 122°F ( 50°C)
Performance
Lifespan
100,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations
LED Characteristics
LEDs
Multi-chip, high-output, long-life LEDs
Electrical
Driver
Class 2, Constant Current, 120-277V, 50/60 Hz, 120V: 1.22A, 208V: 0.71A, 240V: 0.62A, 277V: 0.53A
THD
3.95% at 120V, 6.75% at 277V
Power Factor
99.9% at 120V, 96.9% at 277V
